Ignition Coil & Spark Plug ([12.1989 - ] (8912- )1N) Diagram Toyota STARLET
- Year
- 1989 - 1992
- Sales region
- Japan
- Frame
- NP80
- grade
- X
- ENGINE
- 1N
- TRANSMISSION
- ATM
- From
- 12.1989
- To
- 01.1992
- Gear Shift Type
- 4FC
- No.of Doors
- 5D
- Vehicle Model
- STARLET
- Fuel Induction
- DSL
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
19850
|
19850
19850-54090 Plug Assy, Glow[12.1989 - 09.1995] 1N..NP80 ＊ＢＶ−ＧＶ＝１２Ｖ−１１Ｖ |
19850-54090 |
from US $30.17 |
||
|
19850B
|
19850B
90189-04024 Grommet, Screw(For Glow Plug)[12.1989 - 09.1995] 1N..NP80 |
90189-04024 |
from US $0.72 |
||
|
19856
|
19856
90170-04002 Nut, Connecting(For Glow Plug)[12.1989 - 09.1995] 1N..NP80 |
90170-04002 |
US $1.12 |
||
|
19871
|
19871
19871-55020 Connector, Glow Plug No.1[12.1989 - 09.1995] 1N..NP80 |
19871-55020 |
US $41.35 |
||
|
2862254020
|
2862254020
28622-54020
Insulator, Glow Plug Resistor, No.1
|
28622-54020 |
— | ||
|
2862364010
|
2862364010
28623-64010
Insulator, Glow Plug Resistor, No.2
|
28623-64010 |
— | ||
|
2863355010
|
2863355010
28633-55010 Cover, Current Sensor |
28633-55010 |
US $12.67 |
||
|
9012606001
|
9012606001
90126-06001 STUD HEX LOBULAR |
90126-06001 |
US $2.56 |
||
|
9017906009
|
9017906009
90179-06009
Nut (For Transmission Control Cable)
|
90179-06009 |
— | ||
| replacement | |||||
|
9017906009
|
9017906009
90179-06156 Nut (For Transmission Control Cable) |
90179-06156 |
from US $0.90 |
||
|
9461310601
|
9461310601
94613-10601 Washer (For Primary Regulator Valve) |
94613-10601 |
US $1.12 |
||
