Front Spring & Shock Absorber ([03.1979 - ] (7903- )) Diagram Toyota STOUT
- Year
- 1982 - 1986
- Sales region
- Japan
- Frame
- RK111
- body
- T1
- ENGINE
- 5R
- From
- 01.1982
- To
- 03.1986
- Vehicle Model
- STOUT
- Loading Capacity
- 20T
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
48811
|
48811
48811-35030 Bar, Stabilizer, FrontSTABILIZER, FRONT [03.1979 - 03.1986] RK11# |
48811-35030 |
US $151.42 |
||
|
48815
|
48815
48815-35040
Bush, Front Stabilizer Bar, No.1
[03.1979 - 03.1986] RK11# |
48815-35040 |
— | ||
|
48817
|
48817
90948-01002 Cushion[03.1979 - 03.1986] RK11# |
90948-01002 |
from US $2.75 |
||
|
48817A
|
48817A
90948-02004 Cushion Retainer[03.1979 - 03.1986] RK11# |
90948-02004 |
from US $1.56 |
||
|
48817B
|
48817B
90948-02005 Retainer No.2[03.1979 - 03.1986] RK11# |
90948-02005 |
from US $1.31 |
||
|
48817C
|
48817C
90440-14024 Bush(For Front Stabilizer Bar)[03.1979 - 03.1986] RK11# |
90440-14024 |
US $4 |
||
|
48817D
|
48817D
90101-10259
Bolt(For Front Stabilizer)
[03.1979 - 03.1986] RK11# |
90101-10259 |
— | ||
|
48823
|
48823
48823-36011 Cover, Stabilizer Link(For Front)STABILIZER LINK(FOR FRONT) [03.1979 - 03.1986] RK11# |
48823-36011 |
US $4.95 |
||
|
48824
|
48824
48824-35040 Bracket, Stabilizer, FrontSTABILIZER, FRONT [03.1979 - 03.1986] RK11# RH |
48824-35040 |
US $29.12 |
||
|
48824
|
48824
48829-35030 Bracket, Stabilizer, FrontSTABILIZER, FRONT [03.1979 - 03.1986] RK11# LH |
48829-35030 |
US $18.20 |
||
|
9165140825
|
9165140825
91651-40825 Bolt(For Clutch Release Cylinder Setting) |
91651-40825 |
US $3.20 |
||
|
9411040800
|
9411040800
94110-40800
Nut(For Steering Damper)
|
94110-40800 |
— | ||
| replacement | |||||
|
9411040800
|
9411040800
94130-00802 Nut, No.1 (For Center Support Bearing) |
94130-00802 |
from US $1.03 |
||
|
9411041000
|
9411041000
94110-41000 Nut(For Steering Damper) |
94110-41000 |
US $2.56 |
||
|
9412041000
|
9412041000
94120-41000 Nut(For Clutch Pedal Stopper) |
94120-41000 |
from US $0.80 |
||
| replacement | |||||
|
9412041000
|
9412041000
90170-A0002 Nut |
90170-A0002 |
US $2.33 |
||
|
9451200800
|
9451200800
94512-00800 Washer, No.1 (For Propeller Shaft & Differential Setting) |
94512-00800 |
from US $0.76 |
||
