Planetary Gear, Reverse Piston & Counter Gear(Atm) ([05.1993 - ] A340E (9305- )4FC..TWC) Diagram Toyota SUPRA
- Year
- 1993 - 1998
- Sales region
- Europe
- Frame
- JZA80
- body
- AET
- ENGINE
- 2JZGE
- TRANSMISSION
- ATM
- DESTINATION
- USA
- Model
- SUPRA 80
- From
- 05.1993
- To
- 08.1998
- Gear Shift Type
- 4FC
- Vehicle Model
- SUPRA
- Fuel Induction
- TWC
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
33481S
|
33481S
33481-30060 Gear, Speedometer Drive (Atm)[05.1993 - 09.1997] JZA80..4FC..TWC N=6 |
33481-30060 |
US $18.35 |
||
|
35075
|
35075
35075-30011 Gear Sub-Assy, Front Planetary Ring[05.1993 - 08.1995] JZA80..4FC..TWC |
35075-30011 |
US $420.78 |
||
| replacement | |||||
|
35075
|
35075
35075-50010 Gear Sub-Assy, Front Planetary Ring[05.1993 - 08.1995] JZA80..4FC..TWC |
35075-50010 |
US $269.07 |
||
|
35075
|
35075
35075-50010 Gear Sub-Assy, Front Planetary Ring[08.1995 - 08.1998] JZA80..4FC..TWC |
35075-50010 |
US $269.07 |
||
|
35075A
|
35075A
90374-32004 Bearing, Thrust(For Overdrive Planetary Ring Gear Flange)[05.1993 - 09.1997] JZA80..4FC..TWC |
90374-32004 |
US $13.98 |
||
| replacement | |||||
|
35075A
|
35075A
90374-35004 Bearing, Thrust Needle Roller (For Front Planetary Ring)[05.1993 - 09.1997] JZA80..4FC..TWC |
90374-35004 |
US $11.94 |
||
|
35075A
|
35075A
90374-35004 Bearing, Thrust Needle Roller (For Front Planetary Ring)[09.1997 - 08.1998] JZA80..TWC |
90374-35004 |
US $11.94 |
||
|
35075B
|
35075B
35789-30120 Race, Thrust Bearing (For Front Planetary Ring Gear Front)[05.1993 - 08.1998] JZA80..4FC |
35789-30120 |
US $5.39 |
||
|
35075C
|
35075C
35789-30130 Race, Thrust Bearing (For Front Planetary Ring Gear Rr)[05.1993 - 09.1997] JZA80..4FC..TWC |
35789-30130 |
US $11.07 |
||
|
35481U
|
35481U
90360-06004 Ball, Detent(For Gear Shift Head No.4)[05.1993 - 07.1996] JZA80..4FC |
90360-06004 |
from US $0.82 |
||
| replacement | |||||
|
35481U
|
35481U
90080-36191
Ball, Check Valve
[05.1993 - 07.1996] JZA80..4FC |
90080-36191 |
— | ||
|
35481V
|
35481V
90520-28009 Ring Or Spacer (For Mtm Speedometer Drive Gear)[05.1993 - 08.1998] JZA80..4FC..TWC T=1.50,OD=33.8 |
90520-28009 |
from US $1.44 |
||
|
35481V
|
35481V
90520-32002 Ring Or Spacer (For Atm Speedmeter Drive Gear)[09.1997 - 08.1998] JZA80..TWC T=1.50,OD=37.7 |
90520-32002 |
US $0.96 |
||
|
35720
|
35720
35720-30080 Gear Assy, Front Planetary[05.1993 - 08.1998] JZA80..4FC..TWC |
35720-30080 |
US $391.37 |
||
|
35720A
|
35720A
90374-35001 Bearing, Thrust Needle Roller (For Front Planetary Gear)[05.1993 - 08.1998] JZA80..4FC..TWC |
90374-35001 |
US $16.89 |
||
|
35720B
|
35720B
90520-24026 Ring, Shaft Snap (For Front Planetary Gear)[05.1993 - 08.1998] JZA80..4FC..TWC |
90520-24026 |
US $1.05 |
||
|
35735A
|
35735A
35735-30020 Ring, Planetary Output Shaft Oil Seal[05.1993 - 08.1998] JZA80..4FC |
35735-30020 |
US $10.83 |
||
|
35737A
|
35737A
35737-30030 Washer, Planetary Carrier Thrust, No.1[05.1993 - 08.1998] JZA80..4FC |
35737-30030 |
US $3.06 |
||
|
35738
|
35738
35739-30030 Washer, Planetary Carrier Thrust, No.2[05.1993 - 08.1998] JZA80..4FC |
35739-30030 |
US $4.37 |
||
|
35760
|
35760
35705-30010 Gear Assy, Rear Planetary[05.1993 - 08.1998] JZA80..4FC..TWC |
35705-30010 |
US $382.93 |
||
|
35761
|
35761
35761-30020 Gear, Rear Planetary Ring[05.1993 - 09.1997] JZA80..4FC..TWC |
35761-30020 |
US $101.92 |
||
|
35761
|
35761
35761-50010 Gear, Rear Planetary Ring[09.1997 - 08.1998] JZA80..4FC |
35761-50010 |
US $62.17 |
||
|
35761A
|
35761A
90521-99024 Ring, Hole Snap (For Overdrive Planetary Ring Gear)[05.1993 - 08.1998] JZA80..4FC |
90521-99024 |
US $2.62 |
||
|
35762
|
35762
35762-30040 Flange, Rear Planetary Ring Gear[08.1993 - 08.1998] JZA80..4FC..TWC |
35762-30040 |
US $71.20 |
||
|
35762
|
35762
35762-50010 Flange, Rear Planetary Ring Gear[05.1993 - 08.1993] JZA80..4FC |
35762-50010 |
US $104.83 |
||
|
35762A
|
35762A
90374-39001 Bearing, Thrust Needle Roller (For Rear Planetary Flange)[05.1993 - 08.1998] JZA80..4FC |
90374-39001 |
US $9.46 |
||
| replacement | |||||
|
35762A
|
35762A
90374-38003 Bearing, Thrust Needle Roller (For Rear Planetary Flange)[05.1993 - 08.1998] JZA80..4FC |
90374-38003 |
US $9.32 |
||
|
35771
|
35771
35771-30040 Shaft, Output[05.1993 - 09.1997] JZA80..4FC..TWC |
35771-30040 |
US $311.58 |
||
|
35771
|
35771
35771-30050 Shaft, Output[09.1997 - 08.1998] JZA80..TWC |
35771-30050 |
US $355.26 |
||
|
35789C
|
35789C
35789-30080 Race, Thrust Bearing (For Overdrive Support Front)[05.1993 - 08.1998] JZA80..4FC..TWC |
35789-30080 |
US $5.02 |
||
|
35789D
|
35789D
35789-30100 Race, Thrust Bearing (For Front Planetary Gear Rear)[05.1993 - 08.1998] JZA80..4FC..TWC |
35789-30100 |
US $6.12 |
||
|
35789F
|
35789F
35789-30160 Race, Thrust Bearing (For Rear Planetary Flange)[05.1993 - 08.1998] JZA80..4FC..TWC |
35789-30160 |
US $9.61 |
||
|
35792
|
35792
35792-14020 Clutch, 1 Way, No.2[05.1993 - 08.1998] JZA80..4FC |
35792-14020 |
US $122.30 |
||
|
35792B
|
35792B
90521-87001 Ring, Hole Snap (For Rear Planetary Ring Gear)[05.1993 - 08.1998] JZA80..4FC |
90521-87001 |
US $2.62 |
||
|
35797
|
35797
35797-50010 Race, 1 Way Clutch Inner[05.1993 - 08.1998] JZA80..4FC |
35797-50010 |
US $91.73 |
||
