Disc Wheel & Wheel Cap ([09.1994 - ] (9409- )) Diagram Toyota TERCEL
- Year
- 1994 - 1999
- Sales region
- General
- Frame
- EL50
- ENGINE
- 2E
- TRANSMISSION
- MTM
- DESTINATION
- GEN
- From
- 09.1994
- To
- 07.1999
- Gear Shift Type
- 5F
- Vehicle Model
- TERCEL
- Driver's Position
- RHD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
42601
|
42601
42611-16420-03 Wheel, Disc[09.1994 -] EL5# 13X4.5J,TYPE A:REFER TO ILLUSTRATION,SILVER |
42611-16420-03 |
US $112.11 |
||
|
42601
|
42601
42611-20331-01 Wheel, Disc[09.1994 -] EL5#..GEN 13X5.5J,TYPE B:REFER TO ILLUSTRATION,BLACK |
42611-20331-01 |
US $122.30 |
||
|
42601A
|
42601A
42611-16420-03 Wheel, Disc[09.1994 -] EL5# 13X4.5J,TYPE A:REFER TO ILLUSTRATION,SILVER |
42611-16420-03 |
US $112.11 |
||
|
42601A
|
42601A
42611-20331-01 Wheel, Disc[09.1994 -] EL5#..GEN 13X5.5J,TYPE B:REFER TO ILLUSTRATION,BLACK |
42611-20331-01 |
US $122.30 |
||
|
42601C
|
42601C
90942-01007 Nut, Hub (For Axle)[09.1994 -] EL5# TYPE A:REFER TO ILLUSTRATION |
90942-01007 |
from US $2.07 |
||
|
42601C
|
42601C
90942-01021 Nut, Hub (For Axle)[09.1994 -] EL5# TYPE B:REFER TO ILLUSTRATION |
90942-01021 |
from US $3.22 |
||
|
42611G
|
42611G
90942-05009 Valve (For Tubeless Tire)[09.1994 -] EL5# |
90942-05009 |
from US $6.24 |
||
| replacement | |||||
|
42611G
|
42611G
90080-94031 Valve (For Tubeless Tire)[09.1994 -] EL5# |
90080-94031 |
US $1.66 |
||
|
42611J
|
42611J
90942-05009 Valve (For Tubeless Tire)[09.1994 -] EL5# |
90942-05009 |
from US $6.24 |
||
| replacement | |||||
|
42611J
|
42611J
90080-94031 Valve (For Tubeless Tire)[09.1994 -] EL5# |
90080-94031 |
US $1.66 |
||
|
42652
|
42652
42652-10360
Tire
[12.1995 - 11.1997] EL50..RHD 155SR13,*O/T,HI-STEEL535;*T/Y,NP01;*B/S,SF-213;*Y/H,S-208 |
42652-10360 |
— | ||
|
42652
|
42652
42652-12880
Tire
[09.1994 -] EL5#..GEN 175/70R13 82S |
42652-12880 |
— | ||
|
42652
|
42652
42652-16430
Tire
[09.1994 - 08.1996] EL50..RHD 155SR13,*O/T,HS307;*D/L,SP20FE;*Y/H,S-203;*T/Y,A09 |
42652-16430 |
— | ||
|
42652
|
42652
42652-16530
Tire
[11.1997 - 12.1997] EL50..RHD 155/80R13 |
42652-16530 |
— | ||
|
42652A
|
42652A
42652-10360
Tire
[12.1995 - 11.1997] EL50..RHD 155SR13,*O/T,HI-STEEL535;*T/Y,NP01;*B/S,SF-213;*Y/H,S-208 |
42652-10360 |
— | ||
|
42652A
|
42652A
42652-12880
Tire
[09.1994 -] EL5#..GEN 175/70R13 82S |
42652-12880 |
— | ||
|
42652A
|
42652A
42652-16430
Tire
[09.1994 - 08.1996] EL50..RHD 155SR13,*O/T,HS307;*D/L,SP20FE;*Y/H,S-203;*T/Y,A09 |
42652-16430 |
— | ||
|
42652A
|
42652A
42652-16530
Tire
[11.1997 - 12.1997] EL50..RHD 155/80R13 |
42652-16530 |
— | ||
