Heating & Air Conditioning - Water Piping ([09.1971 - 02.1979] (7109-7902)) Diagram Toyota TOYOACE/ TOWNACE/ MASTERACE/ LITEACE
- Year
- 1971 - 1979
- Sales region
- Europe
- Frame
- RY10
- body
- T1
- ENGINE
- 12R
- Model
- TOYO ACE
- From
- 09.1971
- To
- 02.1979
- Vehicle Model
- TOYO ACE
- Driver's Position
- RHD
- Deck(Material)
- TS
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
87205
|
87205
87251-25070
Joint Or Union, Front Heater Hose Through Or Inlet Valve
[09.1971 - 02.1979] RY10,12 |
87251-25070 |
— | ||
|
87251
|
87251
87251-29020
Joint Or Union, Front Heater Hose Through Or Inlet Valve
[09.1971 - 11.1975] RY10,12 |
87251-29020 |
— | ||
|
87251
|
87251
87251-55050
Joint Or Union, Front Heater Hose Through Or Inlet Valve
[11.1975 - 02.1979] RY10,12 |
87251-55050 |
— |
