Front Spring & Shock Absorber ([09.1971 - 02.1979] (7109-7902)RY10,12) Diagram Toyota TOYOACE/ TOWNACE/ MASTERACE/ LITEACE
- Year
- 1971 - 1979
- Sales region
- Europe
- Frame
- RY10
- body
- T3
- ENGINE
- 12R
- Model
- TOYO ACE
- From
- 09.1971
- To
- 02.1979
- Vehicle Model
- TOYO ACE
- Driver's Position
- RHD
- Deck(Material)
- TS
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
48110
|
48110
48110-25030
Spring Assy, Front, Rh
[09.1971 - 02.1979] RY10 |
48110-25030 |
— | ||
|
48111
|
48111
48111-25030
Leaf, Front Spring, No.1
[09.1971 - 02.1979] RY10,12 |
48111-25030 |
— | ||
|
48112
|
48112
48112-25030
Leaf, Front Spring, No.2
[09.1971 - 02.1979] RY10 |
48112-25030 |
— | ||
|
48113
|
48113
48102-25030
Leaf, Front Spring, No.3
[09.1971 - 02.1979] RY10 |
48102-25030 |
— | ||
|
48114
|
48114
48114-25030
Leaf, Front Spring, No.4
[09.1971 - 02.1979] RY10 |
48114-25030 |
— | ||
|
48120
|
48120
48110-25030
Spring Assy, Front, Rh
[09.1971 - 02.1979] RY10 |
48110-25030 |
— | ||
|
48141
|
48141
48141-35021 Clip, Front Spring, No.1[09.1971 - 02.1979] RY10,12 |
48141-35021 |
US $5.24 |
||
|
48147
|
48147
48247-25020 Bolt, Rear Spring, Center[09.1971 - 02.1979] RY10 |
48247-25020 |
US $4.22 |
||
|
9411040800
|
9411040800
94110-40800
Nut(For Steering Damper)
|
94110-40800 |
— | ||
| replacement | |||||
|
9411040800
|
9411040800
94130-00802 Nut, No.1 (For Center Support Bearing) |
94130-00802 |
from US $0.84 |
||
|
9511100814
|
9511100814
95111-00814
New Genuine Part
|
95111-00814 |
— | ||
