Front Spring & Shock Absorber ([07.1972 - 02.1979] (7207-7902)JY16,RY16) Diagram Toyota TOYOACE/ TOWNACE/ MASTERACE/ LITEACE
- Year
- 1972 - 1979
- Sales region
- Europe
- Frame
- RY16
- body
- T1
- ENGINE
- 5R
- Model
- TOYO ACE
- From
- 07.1972
- To
- 02.1979
- Vehicle Model
- TOYO ACE
- Loading Capacity
- 20T
- Driver's Position
- RHD
- Deck(Material)
- TS
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
48110
|
48110
48110-25070
Spring Assy, Front, Rh
[07.1972 - 08.1977] JY16,RY16 |
48110-25070 |
— | ||
|
48110
|
48110
48110-25110
Spring Assy, Front, Rh
[08.1977 - 02.1979] JY16,RY16..20T |
48110-25110 |
— | ||
|
48111
|
48111
48111-25070
Leaf, Front Spring, No.1
[07.1972 - 08.1977] JY16,RY16 |
48111-25070 |
— | ||
| replacement | |||||
|
48111
|
48111
48111-25500 Leaf, Front Spring, No.1[07.1972 - 08.1977] JY16,RY16 |
48111-25500 |
US $133.95 |
||
|
48111
|
48111
48111-25071
Leaf, Front Spring, No.1
[08.1977 - 02.1979] JY16,RY16..20T |
48111-25071 |
— | ||
| replacement | |||||
|
48111
|
48111
48111-25500 Leaf, Front Spring, No.1[08.1977 - 02.1979] JY16,RY16..20T |
48111-25500 |
US $133.95 |
||
|
48112
|
48112
48102-25070
Leaf, Front Spring, No.2
[07.1972 - 08.1977] JY16,RY16 |
48102-25070 |
— | ||
|
48112
|
48112
48102-25071
Leaf, Front Spring, No.2
[08.1977 - 02.1979] JY16,RY16..20T |
48102-25071 |
— | ||
|
48113
|
48113
48113-25070
Leaf, Front Spring, No.3
[07.1972 - 08.1977] JY16,RY16 |
48113-25070 |
— | ||
| replacement | |||||
|
48113
|
48113
48113-25750 Leaf, Front Spring, No.3[07.1972 - 08.1977] JY16,RY16 |
48113-25750 |
US $66.83 |
||
|
48113
|
48113
48113-25071
Leaf, Front Spring, No.3
[08.1977 - 02.1979] JY16,RY16..20T |
48113-25071 |
— | ||
| replacement | |||||
|
48113
|
48113
48113-25750 Leaf, Front Spring, No.3[08.1977 - 02.1979] JY16,RY16..20T |
48113-25750 |
US $66.83 |
||
|
48114
|
48114
48103-25070
Leaf, Front Spring, No.4
[07.1972 - 08.1977] JY16,RY16 |
48103-25070 |
— | ||
| replacement | |||||
|
48114
|
48114
48103-25071
Leaf, Front Spring, No.4
[07.1972 - 08.1977] JY16,RY16 |
48103-25071 |
— | ||
|
48114
|
48114
48103-25071
Leaf, Front Spring, No.4
[08.1977 - 02.1979] JY16,RY16..20T |
48103-25071 |
— | ||
|
48120
|
48120
48110-25070
Spring Assy, Front, Rh
[07.1972 - 01.1974] JY16,RY16 |
48110-25070 |
— | ||
|
48120
|
48120
48110-25110
Spring Assy, Front, Rh
[08.1977 - 02.1979] JY16,RY16..RHD |
48110-25110 |
— | ||
|
48141
|
48141
48141-36040
Clip, Front Spring, No.1
[07.1972 - 02.1979] JY16,RY16 |
48141-36040 |
— | ||
|
48142
|
48142
48142-36040
Clip, Front Spring, No.2
[07.1972 - 02.1979] JY16,RY16 |
48142-36040 |
— | ||
|
48147
|
48147
48147-36040 Bolt, Front Spring, CenterFRONT SPRING, CENTER [07.1972 - 02.1979] JY16,RY16 |
48147-36040 |
US $5.68 |
||
|
9411040800
|
9411040800
94110-40800
Nut(For Steering Damper)
|
94110-40800 |
— | ||
| replacement | |||||
|
9411040800
|
9411040800
94130-00802 Nut, No.1 (For Center Support Bearing) |
94130-00802 |
from US $1.03 |
||
|
9511100814
|
9511100814
95111-00814
New Genuine Part
|
95111-00814 |
— | ||
