Front Floor Panel & Front Floor Member ([03.1979 - ] (7903- )LHD) Diagram Toyota TOYOACE/ TOWNACE/ MASTERACE/ LITEACE
- Year
- 1979 - 1985
- Sales region
- General
- Frame
- RY20
- body
- T3
- ENGINE
- 12R
- DESTINATION
- GEN
- Model
- TOYO ACE
- From
- 03.1979
- To
- 07.1985
- Gear Shift Type
- 4H
- Vehicle Model
- TOYO ACE
- Loading Capacity
- 15T
- Driver's Position
- LHD
- Building Condition
- CBU
- Rear Tire
- ST
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
58410
|
58410
58401-95014
Cover, Engine Service Hole
[03.1979 - 07.1985] JY30,RY20,3#..LHD |
58401-95014 |
— | ||
|
58410D
|
58410D
58445-95400 Cushion, No.1[03.1979 - 07.1985] JY30,LY20,3#,RY20,3# |
58445-95400 |
US $6.41 |
||
|
58410E
|
58410E
90541-09126 Cushion, No.1[03.1979 - 07.1985] JY30,LY20,3#,RY20,3# |
90541-09126 |
US $2.08 |
||
|
58423
|
58423
58435-95405 Packing, Engine Service Hole Cover, No.2ENGINE SERVICE HOLE COVER, NO.2 [03.1979 - 07.1985] JY30,LY20,3#,RY20,3# |
58435-95405 |
US $51.11 |
||
|
58424
|
58424
58425-95403 Packing, Engine Cover, FrontENGINE SERVICE HOLE COVER, NO.1 [03.1979 - 07.1985] JY30,RY20,3#..LHD |
58425-95403 |
US $22.42 |
||
|
58424A
|
58424A
58414-95400 Packing, Engine Service Hole Cover Sub, No.1[03.1979 - 07.1985] JY30,RY20,3#..LHD |
58414-95400 |
US $12.52 |
||
|
58430
|
58430
58403-95013
Cover Assy, Sub-Floor Service Hole
[03.1979 - 07.1985] JY30,RY20,3#..LHD |
58403-95013 |
— | ||
|
58805
|
58805
71901-95407
Catch Sub-Assy, Engine Service Hole Cover
[03.1979 - 01.1982] JY30,LY20,30,RY20,3# |
71901-95407 |
— | ||
|
58805
|
58805
71901-95408 Catch Sub-Assy, Engine Service Hole CoverENGINE SERVICE HOLE COVER [01.1982 - 07.1985] JY30,LY3#,RY20,3# |
71901-95408 |
US $19.07 |
||
|
58805A
|
58805A
71919-95010 Spacer, Engine Cover CatchENGINE COVER CATCH [03.1979 - 07.1985] JY30,LY3#,RY20,3# |
71919-95010 |
US $4.37 |
||
|
9011908377
|
9011908377
90119-08377
New Genuine Part
|
90119-08377 |
— | ||
|
9163140616
|
9163140616
91631-40616 Bolt(For Head To Camshaft Bearing Cap) |
91631-40616 |
US $2.72 |
||
|
9165540616
|
9165540616
91655-40616
Bolt
|
91655-40616 |
— | ||
| replacement | |||||
|
9165540616
|
9165540616
91651-60614 Bolt |
91651-60614 |
from US $1.12 |
||
|
9324016016
|
9324016016
93240-16016 New Genuine Part |
93240-16016 |
US $1.60 |
||
|
9331215012
|
9331215012
93312-15012 New Genuine Part |
93312-15012 |
US $1.16 |
||
