Roof Headlining & Silencer Pad ([08.1988 - ] (8808- )YR29,32) Diagram Toyota VAN
- Year
- 1988 - 1990
- Sales region
- U.S.A.
- Frame
- YR29
- grade
- STD
- body
- V
- ENGINE
- 4YEC
- TRANSMISSION
- ATM
- DESTINATION
- USA
- From
- 08.1988
- To
- 01.1990
- Gear Shift Type
- 4FC
- Vehicle Model
- VAN
- Side Window
- VSG
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
63304A
|
63304A
63304-28010-03 Trim Sub-Assy, Roof Headlining, FrontROOF HEADLINING, FRONT [08.1988 - 01.1990] YR29,32 GRAY,TRIM1# |
63304-28010-03 |
US $192.19 |
||
|
63304A
|
63304A
63304-28010-04 Trim Sub-Assy, Roof Headlining, FrontROOF HEADLINING, FRONT [08.1988 - 01.1990] YR29,32 LIGHT BLUE,TRIM8# |
63304-28010-04 |
US $192.19 |
||
|
63304A
|
63304A
63304-28010-06 Trim Sub-Assy, Roof Headlining, FrontROOF HEADLINING, FRONT [08.1988 - 01.1990] YR29,32 LIGHT SABLE,TRIM4# |
63304-28010-06 |
US $192.19 |
||
| replacement | |||||
|
63304A
|
63304A
63304-28010-25 Trim Sub-Assy, Roof Headlining, FrontROOF HEADLINING, FRONT [08.1988 - 01.1990] YR29,32 LIGHT SABLE,TRIM4# |
63304-28010-25 |
US $192.19 |
||
|
63305A
|
63305A
63305-28010-03 Trim Sub-Assy, Roof Headlining, No.2ROOF HEADLINING, NO.2 [08.1988 - 01.1990] YR29,32 GRAY,TRIM1# |
63305-28010-03 |
US $116.48 |
||
|
63305A
|
63305A
63305-28010-04 Trim Sub-Assy, Roof Headlining, No.2ROOF HEADLINING, NO.2 [08.1988 - 01.1990] YR29,32 LIGHT BLUE,TRIM8# |
63305-28010-04 |
US $116.48 |
||
|
63305A
|
63305A
63305-28010-06 Trim Sub-Assy, Roof Headlining, No.2ROOF HEADLINING, NO.2 [08.1988 - 01.1990] YR29,32 LIGHT SABLE,TRIM4# |
63305-28010-06 |
US $116.48 |
||
| replacement | |||||
|
63305A
|
63305A
63305-28010-25 Trim Sub-Assy, Roof Headlining, No.2ROOF HEADLINING, NO.2 [08.1988 - 01.1990] YR29,32 LIGHT SABLE,TRIM4# |
63305-28010-25 |
US $116.48 |
||
|
63310D
|
63310D
90468-04008 Clip, Roof Headlining[08.1988 - 01.1990] YR29,32 TYPE B |
90468-04008 |
US $2.13 |
||
|
63310D
|
63310D
90468-04017 Clip, Roof Headlining[08.1988 - 01.1990] YR29,32 TYPE A |
90468-04017 |
US $2.62 |
||
|
63310D
|
63310D
90468-04073
Clip, Roof Headlining
[08.1988 - 01.1990] YR2#,3# TYPE C |
90468-04073 |
— | ||
|
63311A
|
63311A
63311-28050-03 Headlining, Roof No.1ROOF NO.1 [08.1988 - 01.1990] YR29,32 GRAY,TRIM1# |
63311-28050-03 |
US $82.99 |
||
|
63311A
|
63311A
63311-28050-04 Headlining, Roof No.1ROOF NO.1 [08.1988 - 01.1990] YR29,32 LIGHT BLUE,TRIM8# |
63311-28050-04 |
US $82.99 |
||
|
63311A
|
63311A
63311-28050-06 Headlining, Roof No.1ROOF NO.1 [08.1988 - 01.1990] YR29,32 LIGHT SABLE,TRIM4# |
63311-28050-06 |
US $82.99 |
||
|
63352D
|
63352D
63352-28010 Pad, Roof Headlining, No.2ROOF HEADLINING, NO.2 [08.1988 - 01.1990] YR29,32 |
63352-28010 |
US $11.65 |
||
|
63381E
|
63381E
63381-28010 Retainer, Headlining, FrontROOF HEADLINING TRIM, FRONT [08.1988 - 01.1990] YR2#,3# |
63381-28010 |
US $23.59 |
||
|
63391
|
63391
63391-28010-03 Trim, Roof Headlining, FrontROOF HEADLINING, FRONT [08.1988 - 01.1990] YR2#,3# GRAY,TRIM1# |
63391-28010-03 |
US $33.92 |
||
|
63391
|
63391
63391-28010-04
Trim, Roof Headlining, Front
[08.1988 - 01.1990] YR2#,3# LIGHT BLUE,TRIM8# |
63391-28010-04 |
— | ||
|
63391
|
63391
63391-28010-06 Trim, Roof Headlining, FrontROOF HEADLINING, FRONT [08.1988 - 01.1990] YR2#,3# LIGHT SABLE,TRIM4# |
63391-28010-06 |
US $33.92 |
||
| replacement | |||||
|
63391
|
63391
63391-28010-03 Trim, Roof Headlining, FrontROOF HEADLINING, FRONT [08.1988 - 01.1990] YR2#,3# LIGHT SABLE,TRIM4# |
63391-28010-03 |
US $33.92 |
||
|
6222695700
|
6222695700
62226-95700 Garnish, Front Pillar, Lower Lh |
62226-95700 |
US $4.37 |
||
|
9356014010
|
9356014010
93560-14010 SCREW |
93560-14010 |
US $0.96 |
||
