Ignition Coil & Spark Plug ([11.2012 - ] EUROPE STEP4 (1211- )1ADFTV) Diagram Toyota VERSO
- Year
- 2009 - 2015
- Sales region
- Europe
- Frame
- AUR20
- grade
- E
- ENGINE
- 1ADFTV
- TRANSMISSION
- MTM
- Model
- VERSO
- From
- 02.2009
- To
- 03.2015
- Gear Shift Type
- 6F
- Seating Capacity
- 05S
- Vehicle Model
- VERSO
- Driver's Position
- LHD
- Fuel Induction
- DCR
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
19850
|
19850
19850-0R022
Plug Assy, Glow
[02.2009 - 07.2010] 1ADFTV,2ADFHV..AUR2# *BV-GV=12V-11V,(L) |
19850-0R022 |
— | ||
|
19850
|
19850
19850-26022 Plug Assy, GlowGLOW [02.2009 - 07.2010] 1ADFTV,2ADFHV..AUR2# *BV-GV=12V-11V,(J) |
19850-26022 |
US $33.54 |
||
|
19850
|
19850
19850-26030 Plug Assy, Glow[11.2012 -] 1ADFTV..AUR20 *BV-GV=12V-11V |
19850-26030 |
US $33.49 |
||
|
19850B
|
19850B
90189-04024 Grommet, Screw(For Glow Plug)[02.2009 - 07.2010] 1ADFTV,2ADFHV..AUR2# |
90189-04024 |
from US $0.72 |
||
|
19871
|
19871
19871-0R010
Connector, Glow Plug No.1
[11.2012 -] 1ADFTV..AUR20 |
19871-0R010 |
— | ||
|
19871
|
19871
19871-26010
Connector, Glow Plug No.1
[02.2009 - 07.2010] 1ADFTV,2ADFHV..AUR2# |
19871-26010 |
— | ||
|
90178W0008
|
90178W0008
90178-W0008
New Genuine Part
|
90178-W0008 |
— | ||
|
90178W0019
|
90178W0019
90178-W0019
Nut, Cap(For Cylinder Head Cover)
|
90178-W0019 |
— | ||
|
9017004002
|
9017004002
90170-04002 Nut, Connecting(For Glow Plug) |
90170-04002 |
US $1.12 |
||
|
9046705149
|
9046705149
90467-05149 New Genuine Part |
90467-05149 |
US $2.04 |
