Water Pump ([12.2010 - ] (1012- )1NRFE) Diagram Toyota VITZ
- Year
- 2010 - 2018
- Sales region
- Japan
- Frame
- NSP135
- grade
- U
- ENGINE
- 1NRFE
- TRANSMISSION
- CVT
- From
- 12.2010
- No.of Doors
- 5D
- Vehicle Model
- VITZ
- Fuel Induction
- HTWC
- Building Condition
- CBU
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
16100
|
16100
16100-80004
Pump Assy, Engine Water
[12.2010 - 08.2013] 1NRFE..NSP13#..CBU |
16100-80004 |
— | ||
| replacements | |||||
|
16100
|
16100
16100-80010 Pump Assy, Engine Water[12.2010 - 08.2013] 1NRFE..NSP13#..CBU |
16100-80010 |
US $115.02 |
||
|
16100
|
16100
91552-81050 Bolt, No.2(For Alternator)[12.2010 - 08.2013] 1NRFE..NSP13#..CBU |
91552-81050 |
US $1.92 |
||
|
16100
|
16100
16100-80010 Pump Assy, Engine Water[08.2013 - 04.2014] 1NRFE..NSP13#..CBU |
16100-80010 |
US $115.02 |
||
|
16271
|
16271
16271-47031 Gasket, Water PumpWATER PUMP [12.2010 - 04.2014] 1NRFE..NSP13#..CBU |
16271-47031 |
US $7.84 |
||
|
16620
|
16620
16620-47030
Tensioner Assy, V-Ribbed Belt
[12.2010 - 04.2014] 1NRFE..NSP13#..CBU |
16620-47030 |
— | ||
| replacement | |||||
|
16620
|
16620
16620-47031 Tensioner Assy[12.2010 - 04.2014] 1NRFE..NSP13#..CBU |
16620-47031 |
from US $145.44 |
||
|
9155180618
|
9155180618
91551-80618 Bolt, W/washer(For Repair Actuator Set) |
91551-80618 |
US $0.96 |
||
|
9167180820
|
9167180820
91671-80820 Bolt (For Transmission Control Cable Bracket) |
91671-80820 |
from US $0.88 |
||
