Frame Diagram Kawasaki GA550A
- Engine Capacity
- 550
- Sales region
- General
- Colour
- None (NON)
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
130A
|
130A
130B0508
Bolt-flanged,5x8
|
130B0508 |
— | ||
| replacements | |||||
|
130A
|
130A
130BA0508 BOLT-FLANGED |
130BA0508 |
from US $0.95 |
||
|
130A
|
130A
130AA0508
Bolt-flanged
|
130AA0508 |
— | ||
|
130B
|
130B
130B0510 BOLT-FLANGED |
130B0510 |
US $0.76 |
||
| replacements | |||||
|
130B
|
130B
130CA0510 BOLT-FLANGED |
130CA0510 |
from US $0.95 |
||
|
130B
|
130B
130AA0510 BOLT-FLANGED |
130AA0510 |
from US $0.95 |
||
|
130D
|
130D
130B0510 BOLT-FLANGED |
130B0510 |
US $0.76 |
||
| replacements | |||||
|
130D
|
130D
130CA0510 BOLT-FLANGED |
130CA0510 |
from US $0.95 |
||
|
130D
|
130D
130AA0510 BOLT-FLANGED |
130AA0510 |
from US $0.95 |
||
|
130E
|
130E
130B0514 BOLT (5X14) |
130B0514 |
US $0.34 |
||
| replacement | |||||
|
130E
|
130E
130CA0514 BOLT-FLANGED |
130CA0514 |
from US $0.95 |
||
|
221
|
221
221C0306
SCREW-CSK-CROS
|
221C0306 |
— | ||
| replacement | |||||
|
221
|
221
221AB0306 SCREW-CSK-CROS |
221AB0306 |
from US $0.97 |
||
|
224
|
224
224C0514 SCREW-PAN-WP-CROS,5X1 |
224C0514 |
US $0.29 |
||
|
224A
|
224A
224C0616 Screw-pan-wp-cros |
224C0616 |
US $0.95 |
||
| replacement | |||||
|
224A
|
224A
224AB0616 ナベコネジ(ヒラツキ+ジアナ)，6x16 |
224AB0616 |
US $1.11 |
||
|
311
|
311
311B0600
NUT-HEX,6MM
|
311B0600 |
— | ||
| replacement | |||||
|
311
|
311
311AA0600 NUT-HEX,6MM |
311AA0600 |
from US $0.63 |
||
|
311A
|
311A
311M0600 NUT 6MM |
311M0600 |
US $0.40 |
||
|
312
|
312
312B0600 NUT-HEX |
312B0600 |
US $0.95 |
||
| replacement | |||||
|
312
|
312
312AA0600 NUT-HEX |
312AA0600 |
from US $0.94 |
||
|
461
|
461
461F0600
WASHER-SPRING,6MM
|
461F0600 |
— | ||
| replacement | |||||
|
461
|
461
461DA0600 WASHER-SPRING,6MM |
461DA0600 |
from US $0.55 |
||
|
11009
|
11009
11009-2454 GASKET |
11009-2454 |
US $1.44 |
||
|
14024
|
14024
14024-2045-9H COVER |
14024-2045-9H |
US $66.76 |
||
|
14073
|
14073
14073-2063 DUCT |
14073-2063 |
US $19.01 |
||
|
16146
|
16146
16146-2145 COVER ASSY |
16146-2145 |
US $155.66 |
||
|
16146A
|
16146A
16146-2147 COVER ASSY |
16146-2147 |
US $47.16 |
||
|
16146B
|
16146B
16146-6021 COVER ASSY |
16146-6021 |
US $126.23 |
||
|
21013
|
21013
21013-2059 CONDENSER |
21013-2059 |
US $94.48 |
||
|
21119
|
21119
21119-2104 IGNITER |
21119-2104 |
US $98.37 |
||
|
21177
|
21177
21177-2052
CONTROLLER
|
21177-2052 |
— | ||
|
27017
|
27017
27017-2052 LOCK, COVER |
27017-2052 |
US $3.10 |
||
|
53009
|
53009
53009-2054 HINGE |
53009-2054 |
US $2.27 |
||
|
59366
|
59366
59366-2063-9H GRATE |
59366-2063-9H |
US $14.13 |
||
|
92002
|
92002
92002-2283 Bolt |
92002-2283 |
US $1.82 |
||
|
92002A
|
92002A
92002-2284 Bolt |
92002-2284 |
US $3.70 |
||
|
92027
|
92027
92027-2095 COLLAR |
92027-2095 |
US $1.70 |
||
|
92027A
|
92027A
92027-2096 COLLAR |
92027-2096 |
from US $0.82 |
||
|
92037A
|
92037A
92037-2192 CLAMP |
92037-2192 |
US $7.20 |
||
|
92037B
|
92037B
92037-2193 CLAMP |
92037-2193 |
US $1.66 |
||
|
92075
|
92075
92075-2100 DAMPER |
92075-2100 |
US $8.51 |
||
|
92075A
|
92075A
92075-2106 DAMPER |
92075-2106 |
US $12.51 |
||
|
92075B
|
92075B
92075-2107 DAMPER |
92075-2107 |
US $13.27 |
||
