02- oil injection system Diagram Bombardier GS/GSI
- Year
- 1999
- Sales region
- General
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
275000172
Reservoir huile*tank-oil assy.
|
275000172 |
— | ||
| replacement | |||||
|
1
|
1
275000238 Reservoir huile*tank-oil assy. |
275000238 |
US $104.33 |
||
|
2
|
2
275000221 .bouchon huile *cap-oil assy.Includes 2 - 3.; |
275000221 |
US $32.61 |
||
|
3
|
3
293000076
Capuchon press.*cap-snap
|
293000076 |
— | ||
|
4
|
4
275000187
Goulot remplis.*neck-filler
|
275000187 |
— | ||
|
5
|
5
293250029 Joint etanche *gasket |
293250029 |
US $16.13 |
||
|
6
|
6
211100012 Nut-neck filler fuel |
211100012 |
US $14.14 |
||
|
7
|
7
278001401 Capteur huile *sensor-oilIncludes 7 - 11.; |
278001401 |
US $146.85 |
||
|
8
|
8
278000218 Joint de fil *seal-wire |
278000218 |
US $58.70 |
||
|
9
|
9
278000222 Cosse male *terminal-male |
278000222 |
US $21.15 |
||
|
10
|
10
278000217 Bloc 2 circ.fem*housing-tab(f) |
278000217 |
US $54.25 |
||
|
11
|
11
293720008 Passe-fils *grommet |
293720008 |
US $14.89 |
||
|
12
|
12
293710051 Raccord coude90*fitting-elbow |
293710051 |
US $9.13 |
||
|
13
|
13
275000008 Boyau 12mm. *hose-12mm. |
275000008 |
US $57.18 |
||
|
14
|
14
293750001 Tie rap 94mm *tie-rap 94mm |
293750001 |
US $66.50 |
||
|
15
|
15
293750002 Tie rap 142mm *tie-rap 142mm |
293750002 |
US $15.50 |
||
|
16
|
16
293650035 Bride serrage *clamp-tridon |
293650035 |
US $47.75 |
||
|
17
|
17
293650038
Bride serrage *clamp-tridon
|
293650038 |
— | ||
|
18
|
18
275500139
Boyau 6mm. *hose-6mm.
|
275500139 |
— | ||
|
19
|
19
275500398 Soupape retenue*valve-check |
275500398 |
from US $12.38 |
||
|
20
|
20
275000007
Boyau 8mm. *hose-8mm.
|
275000007 |
— | ||
|
21
|
21
275000051
Filtre huile *filter-oil
|
275000051 |
— | ||
| replacement | |||||
|
21
|
21
275000262 Filtre huile *filter-oil |
275000262 |
from US $16.29 |
||
|
22
|
22
293650042 Bride serrage *clamp-oetiker |
293650042 |
US $20.50 |
||
|
23
|
23
293720008 Passe-fils *grommet |
293720008 |
US $14.89 |
||
|
24
|
24
293250075
Joint etanche *gasket
|
293250075 |
— | ||
|
25
|
25
275000190
Restricteur *restrictor
|
275000190 |
— | ||
|
26
|
26
293800038 Loctite 518 *loctite-518 |
293800038 |
US $51.97 |
||
|
27
|
27
275000188
Boyau remplis. *hose-fil.neck
|
275000188 |
— | ||
| replacement | |||||
|
27
|
27
275000230
Boyau remplis. *hose-fil.neck
|
275000230 |
— | ||
|
28
|
28
293650084 Bride serrage *clamp-norma |
293650084 |
US $5.32 |
||
