02- oil injection system Diagram Bombardier GTI
- Year
- 2005
- Sales region
- General
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
275000238 Reservoir huile*tank-oil assy. |
275000238 |
US $104.33 |
||
|
2
|
2
413802900
Huile 2t 12x1 min+r* oil 2t 12x1 mineral
|
413802900 |
— | ||
| replacement | |||||
|
2
|
2
293600117 Huile 2t 12x1 *oil 2t 12x1 mineral |
293600117 |
US $15.64 |
||
|
2
|
2
413803000
Huile 2t 3x1g min+r* oil 2t 3x1g mineral
|
413803000 |
— | ||
|
2
|
2
413803200
Huile 2t baril * oil 2t drum mineral
|
413803200 |
— | ||
|
3
|
3
275000230
Boyau remplis. *hose-fil.neck
|
275000230 |
— | ||
|
4
|
4
293650035 Bride serrage *clamp-tridon |
293650035 |
US $47.75 |
||
|
5
|
5
275000242 Goulot remplis.*neck-filler |
275000242 |
US $18.33 |
||
|
6
|
6
293250132
Joint etanche *gasket
|
293250132 |
— | ||
|
7
|
7
211100013
Nut-neck filler oil
|
211100013 |
— | ||
|
8
|
8
275000186
Bouchon huile *cap-oil assy.
|
275000186 |
— | ||
|
9
|
9
293250025 Joint torique *o ring |
293250025 |
US $10.17 |
||
|
10
|
10
275500015
Chaine bouchon *chain-cap oil
|
275500015 |
— | ||
|
11
|
11
390407900 Rivet-pop 1/8 *rivet-pop 1/8 |
390407900 |
US $96 |
||
|
12
|
12
234032600 Washer-flat din.9021b-a2 |
234032600 |
US $7.10 |
||
|
13
|
13
278001401 Capteur huile *sensor-oilIncludes 13 to 17; |
278001401 |
US $146.85 |
||
|
14
|
14
278000218 Joint de fil *seal-wire |
278000218 |
US $58.70 |
||
|
15
|
15
278000222 Cosse male *terminal-male |
278000222 |
US $21.15 |
||
|
16
|
16
278000217 Bloc 2 circ.fem*housing-tab(f) |
278000217 |
US $54.25 |
||
|
17
|
17
293720008 Passe-fils *grommet |
293720008 |
US $14.89 |
||
|
18
|
18
275500549 Boyau 1/4 *hose-1/4 |
275500549 |
US $190.60 |
||
|
19
|
19
293750002 Tie rap 142mm *tie-rap 142mm |
293750002 |
US $15.50 |
||
|
20
|
20
275000008 Boyau 12mm. *hose-12mm. |
275000008 |
US $57.18 |
||
|
21
|
21
293650084 Bride serrage *clamp-norma |
293650084 |
US $5.32 |
||
|
22
|
22
275500398 Soupape retenue*valve-check |
275500398 |
from US $12.38 |
||
|
23
|
23
293720008 Passe-fils *grommet |
293720008 |
US $14.89 |
||
|
24
|
24
293710051 Raccord coude90*fitting-elbow |
293710051 |
US $9.13 |
||
|
25
|
25
275000007
Boyau 8mm. *hose-8mm.
|
275000007 |
— | ||
|
26
|
26
293750001 Tie rap 94mm *tie-rap 94mm |
293750001 |
US $66.50 |
||
|
27
|
27
275000262 Filtre huile *filter-oil |
275000262 |
from US $16.29 |
||
|
28
|
28
293650042 Bride serrage *clamp-oetiker |
293650042 |
US $20.50 |
||
|
29
|
29
415080000
Gaine *protector tube
|
415080000 |
— | ||
