01- oil separator Diagram Bombardier GTX
- Year
- 2003
- Sales region
- General
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
420811840 Boitier pompe h*oil pump housing |
420811840 |
US $120.31 |
||
|
2
|
2
420837542
Pump shaft assy
|
420837542 |
— | ||
|
3
|
3
420956675 Rotor pompe hui*outer rotor 16mm |
420956675 |
US $38.98 |
||
|
4
|
4
420811850
Couv.pompe huil*oil pump cover
|
420811850 |
— | ||
| replacement | |||||
|
4
|
4
420811851 OIL PUMP COVER |
420811851 |
US $36.06 |
||
|
5
|
5
420641048 Vis hexalob.epa*torx flange screw |
420641048 |
US $19.15 |
||
|
6
|
6
420950970 Joint etanche *gasket |
420950970 |
US $12.19 |
||
|
7
|
7
420641238 Vis hexalob.epa*screw-torx flange |
420641238 |
US $21.10 |
||
|
8
|
8
420811891 Couv.tamis huil*oil sieve cover |
420811891 |
US $91.77 |
||
|
9
|
9
420630240 Anneau etanche *seal ring |
420630240 |
US $0.97 |
||
|
10
|
10
420950850 Joint etanche *gasket |
420950850 |
US $4.05 |
||
|
11
|
11
420256570 Crible d huile *sieve-oil |
420256570 |
US $15.18 |
||
|
12
|
12
420641228 Vis hexalob.epa*torx flange screw |
420641228 |
US $9.45 |
||
|
13
|
13
420641238 Vis hexalob.epa*screw-torx flange |
420641238 |
US $21.10 |
||
|
14
|
14
420641238 Vis hexalob.epa*screw-torx flange |
420641238 |
US $21.10 |
||
|
15
|
15
420630231
Joint etanche *gasket
|
420630231 |
— | ||
|
16
|
16
420956761 Boitier separ. *oil separator housing |
420956761 |
US $101.97 |
||
|
17
|
17
420256880
Interr.pression*oil pressure switch
|
420256880 |
— | ||
| replacement | |||||
|
17
|
17
420256885
Interr.pression*oil tk pres sw
|
420256885 |
— | ||
|
18
|
18
420811962 Couvercle *oil separator cover |
420811962 |
US $156.03 |
||
|
19
|
19
420956660
Soupape fermetu*shut off solenoid
|
420956660 |
— | ||
| replacement | |||||
|
19
|
19
420956661
Soupape fermetu*shut off solenoid
|
420956661 |
— | ||
|
20
|
20
420630540 Joint etanche *gasket |
420630540 |
US $4.05 |
||
|
21
|
21
420939250 Ressort compres*compression spring |
420939250 |
US $10.69 |
||
|
22
|
22
420856055 Disque soupape *valve disc |
420856055 |
US $27.49 |
||
|
23
|
23
420845620 Anneau retenue *retaining ring |
420845620 |
US $1.79 |
||
|
24
|
24
420641048 Vis hexalob.epa*torx flange screw |
420641048 |
US $19.15 |
||
|
25
|
25
420630220
Joint etanche *gasket
|
420630220 |
— | ||
|
26
|
26
420641238 Vis hexalob.epa*screw-torx flange |
420641238 |
US $21.10 |
||
|
27
|
27
420956920
Couv.obturation*plug cover
|
420956920 |
— | ||
| replacement | |||||
|
27
|
27
420956922
Plug cover assembly
|
420956922 |
— | ||
|
28
|
28
420660620 Retaining band |
420660620 |
US $9.44 |
||
| replacement | |||||
|
28
|
28
420660623 Retaining band |
420660623 |
US $9.45 |
||
|
29
|
29
420660090 Support caout. *rubber bracket |
420660090 |
US $5.32 |
||
|
30
|
30
420847970 Entretoise *spacer |
420847970 |
US $7 |
||
|
31
|
31
420827968 Rondelle plate *washer m6 |
420827968 |
US $2.45 |
||
|
32
|
32
420641258 Screw torx flange m6 x 35 |
420641258 |
US $21.85 |
||
|
33
|
33
420851610 Supp.trans.av. *transport bracket front |
420851610 |
US $24.45 |
||
|
34
|
34
420641048 Vis hexalob.epa*torx flange screw |
420641048 |
US $19.15 |
||
|
35
|
35
420956970
Boyau forme *form hose
|
420956970 |
— | ||
|
36
|
36
420851673 Bride serrage *gear clamp |
420851673 |
US $14.76 |
||
|
37
|
37
420851663
Clamp
|
420851663 |
— | ||
|
38
|
38
420641323 Screw |
420641323 |
US $15.35 |
||
|
39
|
39
293800060 Loctite 243 *loctite-243 |
293800060 |
US $31.18 |
||
|
40
|
40
293600039
Huile 4t 12x1 * oil 4t 12x1 synth 5w40
|
293600039 |
— | ||
