Magneto Diagram Arctic Cat ATV 650 650 V-Twin FIS
- Model code
- A2004ISR4BUSR
- Engine Capacity
- 650
- Year
- 2004
- Commercial Name
- 650 V-Twin FIS
- Sales region
- General
- Colour
- Red
- Model
- ATV 650 V-Twin FIS
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
3201-183 Rotor |
3201-183 |
US $731.60 |
||
|
2
|
2
3201-240 KeyWoodruff |
3201-240 |
US $4.37 |
||
|
3
|
3
3201-095 Bolt |
3201-095 |
US $9.92 |
||
|
4
|
4
3201-182 Stator |
3201-182 |
US $648.89 |
||
|
5
|
5
3201-243 CoilPulsing |
3201-243 |
US $124.02 |
||
|
6
|
6
3201-138 Plate |
3201-138 |
US $3.33 |
||
|
7
|
7
3201-111 ScrewCap |
3201-111 |
US $1.09 |
||
|
8
|
8
3201-144
Screw
|
3201-144 |
— | ||
|
9
|
9
3201-382 Clamp |
3201-382 |
US $3.33 |
||
|
10
|
10
3201-381 Clamp |
3201-381 |
US $4.70 |
