Starter motor Diagram Arctic Cat ATV 650 650 V-Twin FIS
- Model code
- A2006IBR4BUSR
- Engine Capacity
- 650
- Year
- 2006
- Commercial Name
- 650 V-Twin FIS
- Sales region
- General
- Colour
- Red
- Model
- ATV 650 V-Twin FIS
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
3201-189 MotorStarter inc. 2-10 and one No. 11 ; |
3201-189 |
US $892.09 |
||
|
2
|
2
3201-186 Washer |
3201-186 |
US $8.95 |
||
|
3
|
3
3201-277 Washer |
3201-277 |
US $9.86 |
||
|
4
|
4
3201-187 Brush setinc. 5, two No. 6, and one No. 11 ; |
3201-187 |
US $101.68 |
||
|
5
|
5
3201-188 SpringBrush |
3201-188 |
US $14.82 |
||
|
6
|
6
3201-338 O-ring |
3201-338 |
US $5.14 |
||
|
7
|
7
3201-278 WasherLock |
3201-278 |
US $9.97 |
||
|
8
|
8
3201-339 O-ring |
3201-339 |
US $14.82 |
||
|
9
|
9
3201-335 O-ring |
3201-335 |
US $14.98 |
||
|
10
|
10
3201-367 Bolt |
3201-367 |
US $15.36 |
||
|
11
|
11
3201-274 Nut |
3201-274 |
US $6.05 |
||
|
12
|
12
3201-146 ScrewCap |
3201-146 |
US $5.70 |
||
|
13
|
13
3201-195 WireLead |
3201-195 |
US $84.30 |
||
|
14
|
14
3201-185 GrommetStarter terminal |
3201-185 |
US $12.34 |
||
|
15
|
15
3201-097 Bolt |
3201-097 |
US $5.74 |
||
|
16
|
16
3201-210 WasherLock |
3201-210 |
US $4.90 |
||
|
17
|
17
3201-197 SwitchMagnetic inc. 18 ; |
3201-197 |
US $219.36 |
||
|
18
|
18
3201-110 Holder |
3201-110 |
US $12.41 |
||
|
19
|
19
3201-200 LimiterStarter |
3201-200 |
US $397.55 |
||
| replacement | |||||
|
19
|
19
3201-446 Limiter,starter |
3201-446 |
US $382.10 |
||
|
20
|
20
3201-174 GearStarter |
3201-174 |
US $138.92 |
||
|
21
|
21
3201-122 ClutchOne-way |
3201-122 |
US $151.29 |
||
|
22
|
22
3201-433 RaceOne-way clutch |
3201-433 |
US $145.13 |
||
|
23
|
23
3201-096 Bolt |
3201-096 |
US $8.66 |
||
