	Description	OEM Part #	Price
1	1 5506-073 Seat, rear - assy Assembly \| (inc. 2-8)	5506-073	US $998.56
2	2 5506-075 Seat, back (inc. 3-4)	5506-075	US $487.89
3	3 5506-072 Frame, rear seat- ptd black Black	5506-072	US $258.56
4	4 8468-617 Screw Machine Black	8468-617	US $2.96
5	5 5506-074 Seat, base (inc. 8)	5506-074	US $308.06
6	6 8468-616 Screw Machine (inc. 8)	8468-616	US $3.52
7	7 5506-226 Bracket,rear seat-ptd black (inc. 8)	5506-226	US $23.85
8	8 0423-915 Screw Assembly; shoulder Assembly \| (inc. 9-11)	0423-915	US $23.76
9	9 2416-936 Cover,seatbelt-rh Right	2416-936	US $23.76
9	9 2416-937 Cover,seatbelt-lh Left	2416-937	US $21.13
10	10 0623-784 Screw Left	0623-784	—
	replacement
10	10 2623-163 Screw, Self-Tapping Left	2623-163	US $9.05
11	11 5506-161 Belt,seat-3pt 15.5" nar cable-assy Assembly	5506-161	US $351.50
12	12 1423-182 Screw,cap-hfh m12x1.75x30 cl10.9 rie blk Assembly	1423-182	US $21.68
13	13 1423-184 Nut,hex flg-nyl lock m12x1.75 cl10 z&y Assembly	1423-184	US $9.04
14	14 1423-183 Screw,cap-hfhm12x1.75x30cl10.9rie w/2353 Assembly	1423-183	US $5.70
15	15 8408-821 Screw Cap Assembly	8408-821	US $6

Rear Seat Assembly (98589) Diagram Arctic Cat WILDCAT Wildcat 4 Metallic Green 16812753-861780
