Rear wheel/chain Diagram Kawasaki KAF620 Mule 2500
- Model code
- KAF620-C3
- Engine Capacity
- 620
- Year
- 1997
- Sales region
- Japan
- Colour
- 00
- Frame
- AF620C 601201 -
- Engine
- AF620AE 000001 -
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- 2WD/4WD/AWD
- 2WD
- Model
- Mule 2500
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
190
|
190
190H1016 BOLT-UPSET-WS,10X16ボルト(アプセツト，10X16 |
190H1016 |
US $3.24 |
||
| replacement | |||||
|
190
|
190
190BA1016 BOLT-UPSET-WS,10X16ボルト(アプセツト，10X16 |
190BA1016 |
from US $1.40 |
||
|
461
|
461
461F1800 WASHER-SPRING,18MMバネザガネ，18MM |
461F1800 |
US $2 |
||
| replacement | |||||
|
461
|
461
461DA1800 WASHER-SPRING,18MMバネザガネ，18MM |
461DA1800 |
from US $1.09 |
||
|
11012
|
11012
11012-1969 CAP,WHEELキヤツプ，ホイ-ル |
11012-1969 |
from US $5.33 |
||
|
13236
|
13236
13236-1180 LEVER-COMP,REAR BRAKEレバ-コンプ，リヤ ブレ-キ パネル，LH |
13236-1180 |
from US $27.53 |
||
|
13236A
|
13236A
13236-1181 LEVER-COMP,REAR BRAKEレバ-コンプ，リヤ ブレ-キ パネル，RH |
13236-1181 |
from US $27.53 |
||
|
27012
|
27012
27012-1396 HOOK,REAR BRAKE LEVERフツク，リヤ ブレ-キ レバ- |
27012-1396 |
from US $13.54 |
||
|
32085
|
32085
32085-1298 STOPPER,REAR BRAKE LEストツパ，リヤ ブレ-キ レバ- |
32085-1298 |
from US $7.62 |
||
|
39020
|
39020
39020-1053 BRACKET-COMP-REAR SUSブラケツトコンプ(リヤサスプ) |
39020-1053 |
US $878.24 |
||
|
41035
|
41035
41035-1306
PANEL-ASSY-BRAKE,RR,L
パネルアツシ(ブレ-キ)，RR，LH |
41035-1306 |
— | ||
|
41035A
|
41035A
41035-1307 PANEL-ASSY-BRAKE,RR,Rパネルアツシ(ブレ-キ)，RR，RH |
41035-1307 |
US $387.24 |
||
|
41038
|
41038
41038-1226 DRUM,REAR BRAKEドラム，リヤ ブレ-キ |
41038-1226 |
from US $241.06 |
||
|
41048
|
41048
41048-1078 SHOE-BRAKEシユ-(ブレ-キ) |
41048-1078 |
from US $36.08 |
||
|
41048A
|
41048A
41048-1079 SHOE-BRAKEシユ-(ブレ-キ) |
41048-1079 |
from US $36.08 |
||
|
42045
|
42045
42045018 NUT CASTLE,18MMナツト，18MM |
42045018 |
from US $7.76 |
||
|
43092
|
43092
43092-1053 CYLINDER,REAR WHEELシリンダ，リヤ ホイ-ル |
43092-1053 |
from US $73.30 |
||
|
49016
|
49016
49016-1151 COVER-SEALカバ-(シ-ル) |
49016-1151 |
from US $5.44 |
||
|
92015
|
92015
92015-1729 NUT,6MMナツト，6MM |
92015-1729 |
from US $2.65 |
||
|
92022
|
92022
92022-1951 WASHER,SPRING,6MMワツシヤ，スプリング，6MM |
92022-1951 |
from US $2.17 |
||
|
92041
|
92041
92041-1053 COTTER,4.0X35コツタ，4.0X35 |
92041-1053 |
from US $2.33 |
||
|
92043
|
92043
92043-1398 PIN,TENSIONピン，テンシヨン |
92043-1398 |
from US $2.79 |
||
|
92045
|
92045
92045-1229 BEARING-BALLベアリング(ボ-ル)，6205DDU |
92045-1229 |
US $26.23 |
||
| replacement | |||||
|
92045
|
92045
92045-1163 BEARING-BALLベアリング(ボ-ル)，6205DDU |
92045-1163 |
from US $29.38 |
||
|
92066
|
92066
92066-1309 PLUGプラグ |
92066-1309 |
from US $3.11 |
||
|
92081
|
92081
92081-1904 SPRING,SHOE CLAMPスプリング，シユ- クランプ |
92081-1904 |
from US $4.90 |
||
|
92093
|
92093
92093-1259 SEAL,REAR BRAKE LEVERシ-ル，リヤ ブレ-キ レバ- |
92093-1259 |
from US $8.87 |
||
|
92093A
|
92093A
92093-1357 SEALシ-ル |
92093-1357 |
from US $13.54 |
||
|
92143
|
92143
92143-1108 COLLARカラ-，25.1X32X23.3 |
92143-1108 |
US $19.82 |
||
| replacement | |||||
|
92143
|
92143
92152-1238 COLLARカラ-，25.1X32X23.3 |
92152-1238 |
from US $10.73 |
||
|
92143A
|
92143A
92143-1650 COLLARカラ-，25.2X38X29.5 |
92143-1650 |
US $23.63 |
||
| replacement | |||||
|
92143A
|
92143A
92152-1239 COLLARカラ-，25.2X38X29.5 |
92152-1239 |
from US $15.39 |
||
|
92144
|
92144
92144-1299 SPRING,BRAKE,LHスプリング，ブレ-キ |
92144-1299 |
from US $5.13 |
||
|
92144A
|
92144A
92144-1300 SPRING,BRAKE,RHスプリング，ブレ-キ |
92144-1300 |
from US $5.18 |
||
|
92144B
|
92144B
92144-1301 SPRING,BRAKEスプリング，ブレ-キ |
92144-1301 |
from US $5.18 |
||
|
92144C
|
92144C
92144-1302 SPRING,ROD,LHスプリング，ロツド，LH |
92144-1302 |
from US $5.13 |
||
|
92144D
|
92144D
92144-1303 SPRING,ROD,RHスプリング，ロツド，RH |
92144-1303 |
from US $4.82 |
||
|
92150
|
92150
92150-1366 BOLTボルト |
92150-1366 |
from US $4.90 |
||
|
92200
|
92200
92200-1139 WASHER,18.5X52X4.5ワツシヤ，18.5X52X4.5 |
92200-1139 |
US $6.80 |
||
| replacement | |||||
|
92200
|
92200
92200-1474 WASHER,18.5X52X4.5ワツシヤ，18.5X52X4.5 |
92200-1474 |
from US $4.67 |
||
