Fenders Diagram Kawasaki KAF620 Mule 3010 4X4 Hardwoods Green HD
- Model code
- KAF620-H3
- Engine Capacity
- 620
- Year
- 2005
- Sales region
- Canada
- Colour
- Camouflage Hardwoods Green Hd (Base 6A) (374)
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- 2WD/4WD/AWD
- 4WD
- Model
- Mule 3010 4X4 Camo
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
130
|
130
130J0616
BOLT-FLANGED,6X16
|
130J0616 |
— | ||
| replacement | |||||
|
130
|
130
130BB0616 BOLT-FLANGED,6X16 |
130BB0616 |
from US $0.95 |
||
|
130A
|
130A
130J0816
BOLT-FLANGED
|
130J0816 |
— | ||
| replacement | |||||
|
130A
|
130A
130BB0816 BOLT-FLANGED |
130BB0816 |
from US $1.43 |
||
|
482
|
482
482L5000
CIRCLIP-TYPE-E
|
482L5000 |
— | ||
| replacement | |||||
|
482
|
482
482EA5000 CIRCLIP-TYPE-E |
482EA5000 |
from US $0.91 |
||
|
482A
|
482A
482L7000 CIRCLIP-TYPE-E |
482L7000 |
US $3.64 |
||
| replacement | |||||
|
482A
|
482A
482EA7000 CIRCLIP-TYPE-E |
482EA7000 |
from US $3.01 |
||
|
554
|
554
554A0600
PIN-SNAP
|
554A0600 |
— | ||
| replacement | |||||
|
554
|
554
554DA0600 PIN-SNAP |
554DA0600 |
from US $1.36 |
||
|
554A
|
554A
554A0800 PIN-SNAP |
554A0800 |
from US $2.09 |
||
| replacement | |||||
|
554A
|
554A
554DA0800 PIN-SNAP |
554DA0800 |
from US $0.63 |
||
|
11012
|
11012
11012-1985 CAP |
11012-1985 |
from US $4.13 |
||
|
11051
|
11051
11051-1756
BRACKET
|
11051-1756 |
— | ||
|
11052A
|
11052A
11052-1369 BRACKET |
11052-1369 |
US $15.40 |
||
|
13070
|
13070
13070-1367 GUIDE,LH |
13070-1367 |
from US $17.27 |
||
|
13070A
|
13070A
13070-1368 GUIDE,RH |
13070-1368 |
from US $17.27 |
||
|
13271
|
13271
13271-1800 PLATE |
13271-1800 |
US $7.29 |
||
|
21083
|
21083
21083-1146 ARM |
21083-1146 |
US $1.62 |
||
|
21083A
|
21083A
21083-1163 ARM |
21083-1163 |
US $49.69 |
||
|
21083B
|
21083B
21083-1172 ARM |
21083-1172 |
US $103.32 |
||
|
21187
|
21187
21187-1085 ARM-ASSY |
21187-1085 |
US $36.05 |
||
|
27012
|
27012
27012-1608 HOOK |
27012-1608 |
US $61.33 |
||
|
35004A
|
35004A
35004-0018-374
FENDER-FRONT,C.H.GREE
|
35004-0018-374 |
— | ||
|
35063
|
35063
35063-1203 STAY,FR FENDER |
35063-1203 |
US $62.61 |
||
|
39156
|
39156
39156-0014 PAD,FRONT FENDER |
39156-0014 |
US $171.29 |
||
|
39156B
|
39156B
39156-1685 PAD |
39156-1685 |
from US $12.12 |
||
|
92009
|
92009
92009-1621
SCREW
|
92009-1621 |
— | ||
| replacement | |||||
|
92009
|
92009
92009-1694 SCREW |
92009-1694 |
from US $5.13 |
||
|
92015
|
92015
92015-1678 NUT |
92015-1678 |
from US $3.17 |
||
|
92022
|
92022
92022-1317 WASHER,8.5X20X1.6,BLA |
92022-1317 |
from US $2.69 |
||
|
92022A
|
92022A
92022-1346 WASHER,6.5X20X1.6.BLA |
92022-1346 |
from US $0.82 |
||
|
92039
|
92039
92039-1229
RIVET
|
92039-1229 |
— | ||
| replacement | |||||
|
92039
|
92039
92039-0776 RIVET |
92039-0776 |
from US $1.40 |
||
|
92039A
|
92039A
92039-1244 RIVET |
92039-1244 |
from US $1.71 |
||
|
92043
|
92043
92043-1625 PIN,6X39 |
92043-1625 |
from US $1.40 |
||
|
92043A
|
92043A
92043-1626 PIN,6X9 |
92043-1626 |
from US $1.24 |
||
|
92071
|
92071
92071-019 GROMMET HARNESS 10MM |
92071-019 |
from US $2.69 |
||
|
92143
|
92143
92143-1087 COLLAR |
92143-1087 |
from US $2.85 |
||
|
92144
|
92144
92144-1174 SPRING,SEAT HOOK |
92144-1174 |
from US $3.89 |
||
|
92145
|
92145
92145-1335 SPRING |
92145-1335 |
from US $3.43 |
||
|
92161
|
92161
92161-1197 DAMPER |
92161-1197 |
from US $2.95 |
||
|
92200
|
92200
92200-1592 WASHER |
92200-1592 |
from US $1.56 |
||
