Front fork ('84 klt200-c2) Diagram Kawasaki KLT 200
- Model code
- KLT200-C2
- Engine Capacity
- 200
- Year
- 1984
- Sales region
- USA
- Stroke (2-stroke or 4-stroke)
- 4 stroke
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
113
|
113
113B1455 BOLT HEX HEAD 14X55 |
113B1455 |
US $7.15 |
||
|
160
|
160
160B1-020 BOLT-FINE-WS |
160B1-020 |
US $27.50 |
||
|
160A
|
160A
160B1-040 BOLT-FINE-WS |
160B1-040 |
US $43.60 |
||
|
11012
|
11012
11012-4004 CAP |
11012-4004 |
US $3.55 |
||
|
32085
|
32085
32085-4006 STOPPER |
32085-4006 |
US $18.18 |
||
|
39007
|
39007
39007-4003 ARM-SUSP |
39007-4003 |
US $94.27 |
||
|
42036
|
42036
42036-4003 SLEEVE,14X20X25.3Sleeve,14x20x25.3; |
42036-4003 |
US $14.87 |
||
|
44001
|
44001
44001-4010-8G FORK FRONT,EBONYFork front,ebony; |
44001-4010-8G |
US $264.31 |
||
|
44001A
|
44001A
44001-4010-8R FRONT FORK,REDFront fork,red; |
44001-4010-8R |
US $253.80 |
||
|
44039
|
44039
44039-4003
HOLDER-FORK UPPER
|
44039-4003 |
— | ||
|
45014
|
45014
45014-4011-8G Shock absorber,blackShockabsorber,black; |
45014-4011-8G |
US $142.78 |
||
|
92001
|
92001
92001-1742
BOLT
|
92001-1742 |
— | ||
|
92001A
|
92001A
92001-4018 BOLT,12X45Bolt,12x45; |
92001-4018 |
US $5.62 |
||
|
92015
|
92015
92019-011
NUT-LOCK,14MM
Nut-lock,14mm; |
92019-011 |
— | ||
|
92015A
|
92015A
92019-009 NUT-LOCK,12MMNut-lock,12mm; |
92019-009 |
US $8.91 |
||
| replacement | |||||
|
92015A
|
92015A
92210-1373 NUT,LOCK,12MMNut-lock,12mm; |
92210-1373 |
from US $3.96 |
||
|
92015B
|
92015B
92019-021
Nut,lock,10m/m
Nut,lock,10mm; |
92019-021 |
— | ||
| replacements | |||||
|
92015B
|
92015B
92210-1184 NUTNut,lock,10mm; |
92210-1184 |
from US $4.09 |
||
|
92015B
|
92015B
92015-1962 NUTNut,lock,10mm; |
92015-1962 |
from US $3.33 |
||
|
92022
|
92022
92022-1381
WASHER
|
92022-1381 |
— | ||
|
92022A
|
92022A
92022-1057 WASHER,PLAIN,12 X 22Washer,plain,12 x 22; |
92022-1057 |
US $4.25 |
||
|
92028
|
92028
92028-4001
BUSHING,SWING ARM
Bushing,swing arm; |
92028-4001 |
— | ||
|
92048
|
92048
92047-010 CONE STERNG BERG LOWCone sterng berg low; |
92047-010 |
from US $9.66 |
||
|
92093
|
92093
44010-027 SEAL,STEERING STEMSeal,steering stem; |
44010-027 |
US $9.23 |
||
