Front fender(s) Diagram Kawasaki KSF250 Mojave 250
- Model code
- KSF250-A15
- Engine Capacity
- 245
- Year
- 2001
- Sales region
- USA
- Colour
- Lime Green (7F)
- Power
- 20 hp
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- 2WD/4WD/AWD
- 2WD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
130
|
130
130P0612 BOLT-FLANGED,6X12 |
130P0612 |
US $3.13 |
||
| replacement | |||||
|
130
|
130
130CA0612 BOLT-FLANGED,6X12 |
130CA0612 |
from US $2.53 |
||
|
180
|
180
180D0635 BOLT-UPSET-WS |
180D0635 |
US $2.79 |
||
| replacements | |||||
|
180
|
180
180C0635 BOLT-UPSET-WS,6X35 |
180C0635 |
US $2.86 |
||
|
180
|
180
180AA0635 BOLT-UPSET-WS |
180AA0635 |
from US $1.09 |
||
|
11044
|
11044
11044-1934 BRACKET,FLAP |
11044-1934 |
US $8.24 |
||
|
14024
|
14024
14024-1268-6D COVER,FRONT FENDER,BL |
14024-1268-6D |
US $45.24 |
||
|
14024A
|
14024A
14024-1297
COVER,FRONT
|
14024-1297 |
— | ||
|
35004
|
35004
35004-1379-6W
FENDER-FRONT, GREEN
|
35004-1379-6W |
— | ||
|
35011
|
35011
35011-1324 STAY |
35011-1324 |
from US $7.46 |
||
|
35011A
|
35011A
35011-1637-CC STAY,FLAP,L. GREEN |
35011-1637-CC |
US $30.20 |
||
|
35011C
|
35011C
35011-1642-CC STAY,FRONT FENDER |
35011-1642-CC |
US $40.45 |
||
| replacement | |||||
|
35011C
|
35011C
35063-1169 STAY,FRONT FENDER |
35063-1169 |
US $40.45 |
||
|
35019
|
35019
35019-1172
FLAP,LH
|
35019-1172 |
— | ||
|
35019A
|
35019A
35019-1173 FLAP,RH |
35019-1173 |
US $26.66 |
||
|
92009
|
92009
92009-1256 SCREW,6X22,BLACK |
92009-1256 |
from US $1.74 |
||
|
92009A
|
92009A
92009-1508 SCREW,16MM |
92009-1508 |
from US $3.27 |
||
|
92015
|
92015
92015-1233 NUT,FLANGED,6MM |
92015-1233 |
from US $3.90 |
||
|
92015A
|
92015A
92015-1678 NUT |
92015-1678 |
from US $3.17 |
||
|
92015B
|
92015B
92015-1701 NUT |
92015-1701 |
from US $6.68 |
||
|
92027
|
92027
92027-1933 COLLAR,L=5.6 |
92027-1933 |
from US $3.48 |
||
|
92075
|
92075
92075-023 DAMPER RUBB DUAL SEAT |
92075-023 |
from US $3.81 |
||
|
92075A
|
92075A
92075-1834 DAMPER |
92075-1834 |
from US $4.98 |
||
|
92075B
|
92075B
92075-222 DAMPER RUBBER,CASE |
92075-222 |
from US $4.12 |
||
|
92143
|
92143
92143-1016 COLLAR,L=9.6 |
92143-1016 |
from US $3.64 |
||
|
92150
|
92150
92150-1358 BOLT,FLANGED,6X16 |
92150-1358 |
from US $3.17 |
||
|
92172
|
92172
92172-0002 SCREW,6X18 |
92172-0002 |
from US $1.27 |
||
|
92172A
|
92172A
92172-0004 SCREW,6X14 |
92172-0004 |
from US $1.27 |
||
