Handlebar Diagram Kawasaki KSF450 KFX 450R
- Model code
- KSF450BAF
- Engine Capacity
- 449
- Year
- 2010
- Sales region
- USA
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- 2WD/4WD/AWD
- 2WD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
130
|
130
130CA0520 BOLT-FLANGED,5X20 |
130CA0520 |
from US $0.79 |
||
|
220
|
220
220AB0535 SCREW-PAN-CROSS,5X35 |
220AB0535 |
from US $0.95 |
||
|
11054
|
11054
11054-1824 BRACKET,SWITCH BOX ST |
11054-1824 |
from US $4.35 |
||
|
13168
|
13168
13168-0152 LEVER |
13168-0152 |
from US $4.67 |
||
|
13280
|
13280
13280-0204 HOLDER,CLUTCH LEVER |
13280-0204 |
from US $38.10 |
||
|
14091
|
14091
14091-0729 COVER |
14091-0729 |
from US $12.68 |
||
|
27010
|
27010
27010-0061 SWITCH,CLUTCH |
27010-0061 |
from US $24.26 |
||
|
39156
|
39156
39156-0997 PAD,HANDLE |
39156-0997 |
US $44.06 |
||
|
43106
|
43106
43106-0001 LEVER-ASSY-PARKING BR |
43106-0001 |
from US $81.81 |
||
|
46003
|
46003
46003-0119 HANDLE |
46003-0119 |
US $220.83 |
||
|
46012
|
46012
46012-0043 HOLDER-HANDLE,LWR |
46012-0043 |
from US $26.28 |
||
|
46012A
|
46012A
46012-0044 HOLDER-HANDLE,UPP |
46012-0044 |
from US $13.84 |
||
|
46012B
|
46012B
46012-0045 HOLDER-HANDLE |
46012-0045 |
from US $16.33 |
||
|
46018
|
46018
46018-0061 GRIP-ASSY-THROTTLE |
46018-0061 |
US $213.88 |
||
| replacement | |||||
|
46018
|
46018
46018-0234 GRIP-ASSY-THROTTLE |
46018-0234 |
from US $171.07 |
||
|
46075
|
46075
46075-0065 GRIP |
46075-0065 |
US $34 |
||
|
46076
|
46076
46076-0038 LEVER-ASSY-GRIP,CLUTC |
46076-0038 |
from US $104.36 |
||
|
46091
|
46091
46091-0097 HOUSING-ASSY-CONTROL, |
46091-0097 |
from US $87.71 |
||
|
46092
|
46092
46092-0024 LEVER-GRIP |
46092-0024 |
from US $10.73 |
||
|
46092A
|
46092A
46092-0025 LEVER-GRIP,CLUTCH |
46092-0025 |
from US $16.80 |
||
|
49006
|
49006
49006-0027 BOOT,CLUTCH CABLE |
49006-0027 |
from US $5.54 |
||
|
49006A
|
49006A
49006-0046 BOOT |
49006-0046 |
from US $4.51 |
||
|
92009
|
92009
92009-1671 SCREW,5X6 |
92009-1671 |
from US $3.96 |
||
|
92019
|
92019
92019-008 NUT |
92019-008 |
from US $2.53 |
||
|
92022
|
92022
92022-1380 WASHER,5.2X13X1 |
92022-1380 |
from US $2.69 |
||
|
92151
|
92151
92151-1537 BOLT,FLANGED,8X35 |
92151-1537 |
from US $1.74 |
||
|
92153
|
92153
92153-0773 BOLT,BOLT ADJUSTING |
92153-0773 |
from US $6.81 |
||
|
92153A
|
92153A
92153-0807 BOLT |
92153-0807 |
from US $1.11 |
||
|
92153B
|
92153B
92153-1718 BOLT |
92153-1718 |
from US $2.79 |
||
|
92153C
|
92153C
92153-1906 BOLT |
92153-1906 |
from US $1.24 |
||
|
92161
|
92161
92161-1084 DAMPER |
92161-1084 |
from US $1.58 |
||
|
92172
|
92172
92172-0261 SCREW,5MM |
92172-0261 |
from US $1.56 |
||
|
92172A
|
92172A
92172-0332 SCREW,5X38 |
92172-0332 |
from US $1.87 |
||
|
92172B
|
92172B
92172-0342 SCREW,4X16 |
92172-0342 |
from US $1.56 |
||
|
92210
|
92210
92210-0167 NUT,BOLT WIRE ADJUSTI |
92210-0167 |
from US $19.01 |
||
|
92210A
|
92210A
92210-1080 NUT |
92210-1080 |
from US $6.49 |
||
