Cooling Diagram Kawasaki KSF80 KFX 80
- Model code
- KSF80A6F
- Engine Capacity
- 79
- Year
- 2006
- Sales region
- Canada
- Colour
- Lime Green No.2 (908)
- Power
- 4 hp
- Stroke (2-stroke or 4-stroke)
- 2 stroke
- 2WD/4WD/AWD
- 2WD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
11061
|
11061
11061-S061 GASKET,COOLING FAN CO |
11061-S061 |
US $3.04 |
||
|
11061A
|
11061A
11061-S062 GASKET,COOLING FAN CO |
11061-S062 |
US $9.03 |
||
|
14073
|
14073
14073-S007 DUCT,BELT COOLING,OUT |
14073-S007 |
US $22.72 |
||
|
14073A
|
14073A
14073-S008 DUCT,COOLING,OUT |
14073-S008 |
US $22.72 |
||
|
14073B
|
14073B
14073-S009
DUCT,COOLING,OUT
|
14073-S009 |
— | ||
|
14073C
|
14073C
14073-S010 DUCT,COOLING,IN |
14073-S010 |
US $47.30 |
||
|
14091
|
14091
14091-S074 COVER,COOLING FAN |
14091-S074 |
US $45.46 |
||
|
14091A
|
14091A
14091-S075 COVER,COOLING |
14091-S075 |
US $55.28 |
||
|
59041
|
59041
59041-S001 FAN,COOLING |
59041-S001 |
US $21.68 |
||
|
92004
|
92004
92004-S009 STUD,COOLING COWLING |
92004-S009 |
US $1.67 |
||
|
92033
|
92033
92033-S031 RING-SNAP |
92033-S031 |
US $6.07 |
||
|
92066
|
92066
92066-S023 PLUG,DRAIN |
92066-S023 |
US $3.88 |
||
|
92093
|
92093
92093-S019 SEAL,COOLING COWLING |
92093-S019 |
US $29.95 |
||
|
92153
|
92153
92153-S012 BOLT |
92153-S012 |
from US $1.27 |
||
| replacement | |||||
|
92153
|
92153
92153-S502 BOLT |
92153-S502 |
from US $0.94 |
||
|
92171
|
92171
92171-S066 CLAMP,BELT COOLING |
92171-S066 |
US $7.41 |
||
|
92171A
|
92171A
92171-S067 CLAMP,BELT COOLING |
92171-S067 |
US $4.77 |
||
|
92171B
|
92171B
92171-S074 CLAMP |
92171-S074 |
US $7.09 |
||
|
92171C
|
92171C
92171-S075 CLAMP |
92171-S075 |
US $3.35 |
||
|
92171D
|
92171D
92171-S076 CLAMP |
92171-S076 |
US $6.93 |
||
|
92171E
|
92171E
92171-S082 CLAMP,BRAKE PIPE |
92171-S082 |
US $5.47 |
||
| replacement | |||||
|
92171E
|
92171E
92171-S092 CLAMP,BRAKE PIPE |
92171-S092 |
US $42.30 |
||
|
92172
|
92172
92172-S055 SCREW |
92172-S055 |
from US $1.21 |
||
| replacement | |||||
|
92172
|
92172
92172-S296 SCREW |
92172-S296 |
from US $0.94 |
||
|
92172A
|
92172A
92172-S142 SCREW |
92172-S142 |
US $1.21 |
||
| replacement | |||||
|
92172A
|
92172A
92172-S325 SCREW |
92172-S325 |
US $1.21 |
||
|
92172B
|
92172B
92172-S143 SCREW |
92172-S143 |
US $1.19 |
||
| replacement | |||||
|
92172B
|
92172B
92172-S376 SCREW |
92172-S376 |
from US $0.94 |
||
|
92172C
|
92172C
92172-S162 SCREW |
92172-S162 |
US $1.44 |
||
| replacement | |||||
|
92172C
|
92172C
92172-S355 SCREW |
92172-S355 |
US $24.80 |
||
|
92200
|
92200
92200-S003 WASHER |
92200-S003 |
from US $1.24 |
||
| replacement | |||||
|
92200
|
92200
92200-S286 WASHER |
92200-S286 |
from US $0.94 |
||
|
92210
|
92210
92210-S066 NUT |
92210-S066 |
US $3.47 |
||
