Rear fender(s) Diagram Kawasaki KSF90 KFX 90
- Model code
- KSF90ACF
- Engine Capacity
- 89
- Year
- 2012
- Sales region
- Canada
- Colour
- Lime Green (930)
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- 2WD/4WD/AWD
- 2WD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
14091
|
14091
14091-Y009-933 COVER,SIDE,RH,BLACK |
14091-Y009-933 |
US $70.09 |
||
|
14091A
|
14091A
14091-Y010-933 COVER,SIDE,LH,BLACK |
14091-Y010-933 |
US $70.09 |
||
|
16073
|
16073
16073-Y003 INSULATOR |
16073-Y003 |
US $11.14 |
||
|
35023
|
35023
35023-Y001-930 FENDER-REAR,GREEN |
35023-Y001-930 |
from US $69.60 |
||
| replacement | |||||
|
35023
|
35023
35023-Y005-930 Fender-Rear,L.green |
35023-Y005-930 |
US $113.41 |
||
|
55020
|
55020
55020-Y002 GUARD,SIDE,RH |
55020-Y002 |
US $58.91 |
||
|
55020A
|
55020A
55020-Y003 GUARD,SIDE,LH |
55020-Y003 |
US $58.91 |
||
|
92033
|
92033
92033-Y010 RIVET, PLASTIC |
92033-Y010 |
US $2.13 |
||
|
92152
|
92152
92152-Y014 COLLAR |
92152-Y014 |
US $2.45 |
||
|
92153
|
92153
92153-Y018 BOLT,6X16 |
92153-Y018 |
from US $0.78 |
||
|
92153A
|
92153A
92153-Y019 BOLT,6X20 |
92153-Y019 |
US $1.75 |
||
|
92153B
|
92153B
92153-Y032 BOLT,FLANGE,8X16 |
92153-Y032 |
US $1.94 |
||
|
92161
|
92161
92161-Y003 DAMPER |
92161-Y003 |
from US $0.94 |
||
|
92161A
|
92161A
92161-Y005 DAMPER |
92161-Y005 |
US $2.26 |
||
|
92172
|
92172
92172-Y004 SCREW,6X16 |
92172-Y004 |
US $3.91 |
||
|
92210
|
92210
92210-Y031 NUT |
92210-Y031 |
US $2.45 |
||
