Gear change drum/shift fork(s) Diagram Kawasaki KVF400 Prairie 400
- Model code
- KVF400-B1
- Engine Capacity
- 391
- Year
- 1998
- Sales region
- Canada
- Frame
- JKAVFKB1 WB500001 - 999999
- Power
- 25 hp
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- 2WD/4WD/AWD
- 2WD
- Model
- Prairie 400
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
13107
|
13107
13107-1363 SHAFT,IDLER |
13107-1363 |
US $70.43 |
||
|
13260
|
13260
13260-1578 GEAR,FORWARD/LOW,24T |
13260-1578 |
US $81.85 |
||
|
13260A
|
13260A
13260-1642 GEAR,COUNTER HI,37T |
13260-1642 |
US $85.95 |
||
|
13260B
|
13260B
13260-1671 GEAR,IDLER,33T |
13260-1671 |
US $81.85 |
||
|
39135
|
39135
39135-1056 SPROCKET-DRIVEN,33T |
39135-1056 |
US $114.26 |
||
|
92022
|
92022
92022-1800 WASHER,25.3X32X1 |
92022-1800 |
from US $2.79 |
||
|
92033
|
92033
92033-026 CIRCLIP |
92033-026 |
from US $6.72 |
