Gear change drum & forks Diagram Kawasaki KVF400 Prairie 400 4X4
- Model code
- KVF400-C3
- Engine Capacity
- 391
- Year
- 2001
- Sales region
- Japan
- Colour
- Colored Plastic Hunter Green (6A)
- Engine
- VF400AE 500001 -
- Power
- 25 hp
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- 2WD/4WD/AWD
- 4WD
- Model
- Prairie 400 4X4
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
13107
|
13107
13107-1413 SHAFT,IDLERシヤフト，アイドラ |
13107-1413 |
US $73.57 |
||
|
13139
|
13139
13139-1084 SHIFTER,FORWARD HI&REシフタ，フオワ-ド ハイリバ-ス |
13139-1084 |
from US $69.52 |
||
|
13139A
|
13139A
13139-1088 SHIFTER,FORWARD LOWシフタ，フオワ-ド ロウ |
13139-1088 |
US $78.71 |
||
|
13260
|
13260
13260-1734 GEAR,FORWARD LOW,49Tギヤ，フオワ-ド LOW，49T |
13260-1734 |
US $114.61 |
||
|
13260A
|
13260A
13260-1735 GEAR,IDLE SHAFT,36Tギヤ，アイドル シヤフト，36T |
13260-1735 |
US $90.18 |
||
|
13260B
|
13260B
13260-1737 GEAR,FORWARD HI,42Tギヤ，フオワ-ド HIGH，42T |
13260-1737 |
from US $97.04 |
||
|
39135
|
39135
39135-1058 SPROCKET-DRIVEN,REVERスプロケツト(ドリブン)，リバ-ス，42T |
39135-1058 |
US $135.70 |
||
|
92022
|
92022
92022-1731 WASHER,28.1X34X1.0ワツシヤ，28.1X34X1.0 |
92022-1731 |
from US $3.89 |
||
|
92026
|
92026
92026-1066 SPACER,NEEDLE BEARINGスペ-サ，20.3X30X1.8 |
92026-1066 |
from US $5.44 |
||
|
92033
|
92033
92033-026 CIRCLIPリング(スナツプ)，24MM |
92033-026 |
from US $6.72 |
||
|
92033A
|
92033A
92033-1037 SNAP RING,25.9X1.2Tリング(スナツプ)，25.9X30.6X1.2 |
92033-1037 |
from US $2.85 |
||
|
92200
|
92200
92200-1400 WASHER,24.2X32X0.50ワツシヤ，24.2X32X0.50 |
92200-1400 |
from US $1.40 |
