Rear suspension Diagram Kawasaki KVF400 Prairie 400 4X4
- Model code
- KVF400-C3
- Engine Capacity
- 391
- Year
- 2001
- Sales region
- Japan
- Colour
- Colored Plastic Hunter Green (6A)
- Engine
- VF400AE 500001 -
- Power
- 25 hp
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- 2WD/4WD/AWD
- 4WD
- Model
- Prairie 400 4X4
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
130
|
130
130J0612
BOLT-FLANGED,6X12
ボルト(ツバツキ)，6X12 |
130J0612 |
— | ||
| replacement | |||||
|
130
|
130
130BB0612 BOLT-FLANGED,6X12ボルト(ツバツキ)，6X12 |
130BB0612 |
from US $1.43 |
||
|
132
|
132
132J0612
BOLT-FLANGED-SMALL,6X
ボルト(コガタツバツキ)，6X12 |
132J0612 |
— | ||
| replacement | |||||
|
132
|
132
132BB0612 BOLT-FLANGED-SMALL,6Xボルト(コガタツバツキ)，6X12 |
132BB0612 |
from US $0.95 |
||
|
320
|
320
320G1200 Nut-castleミゾツキ ナツト |
320G1200 |
US $1.43 |
||
| replacements | |||||
|
320
|
320
92210-7501 NUT,12MMミゾツキ ナツト |
92210-7501 |
from US $1.90 |
||
|
320
|
320
320BA1200 NUT,12MMミゾツキ ナツト |
320BA1200 |
from US $1.43 |
||
|
320A
|
320A
320H1000 NUT-CASTLEミゾツキ ナツト |
320H1000 |
US $6.80 |
||
| replacement | |||||
|
320A
|
320A
320BA1000 NUT-CASTLEミゾツキ ナツト |
320BA1000 |
from US $1.24 |
||
|
480
|
480
480J3200 CIRCRIP-TYPE-Cトメワ(ジクヨウ)，32MM |
480J3200 |
from US $1.43 |
||
|
550
|
550
550D2015
PIN-COTTER,2.0X15
ワリ ピン，2.0X15 |
550D2015 |
— | ||
| replacement | |||||
|
550
|
550
550AA2015 PIN-COTTER,2.0X15ワリ ピン，2.0X15 |
550AA2015 |
from US $0.63 |
||
|
550A
|
550A
550D3025 PIN-COTTER,3.0X25ワリ ピン，3.0X25 |
550D3025 |
from US $0.27 |
||
| replacement | |||||
|
550A
|
550A
550AA3025 PIN-COTTER,3.0X25ワリ ピン，3.0X25 |
550AA3025 |
from US $0.95 |
||
|
39007
|
39007
39007-1290 ARM-SUSP,FR,LWR,LHア-ム(サスプ)，FR，LWR，LH |
39007-1290 |
US $71.64 |
||
|
39007A
|
39007A
39007-1291 ARM-SUSP,FR,LWR,RHア-ム(サスプ)，FR，LWR，RH |
39007-1291 |
US $71.64 |
||
|
39186
|
39186
39186-0008 KNUCKLE,LHナツクル，FR，LH |
39186-0008 |
from US $248.18 |
||
|
39186A
|
39186A
39186-0009
KNUCKLE,RH
ナツクル，FR，RH |
39186-0009 |
— | ||
|
55020A
|
55020A
55020-0217 GUARD,RHガ-ド，RH |
55020-0217 |
from US $12.76 |
||
|
55020
|
55020
55020-0216 GUARD,LHガ-ド，LH |
55020-0216 |
US $10.93 |
||
|
59266
|
59266
59266-1115 JOINT-BALLジヨイント(ボ-ル) |
59266-1115 |
from US $68.11 |
||
|
92002
|
92002
92002-1861 BOLT,FLANGED,12X67ボルト，フランジ，12X67 |
92002-1861 |
from US $7.44 |
||
|
92022
|
92022
92022-1344 WASHER,7X16X1.2ワツシヤ，7X16X1.2 |
92022-1344 |
from US $2.53 |
||
|
92022A
|
92022A
92022-1829 WASHER,10.2X16X1ワツシヤ，10.2X16X1 |
92022-1829 |
from US $2.69 |
||
|
92033
|
92033
92033-1218 RING-SNAP,30MMリング(スナツプ)，30MM |
92033-1218 |
from US $4.05 |
||
|
92033A
|
92033A
92033-1274 RING-SNAPリング(スナツプ)，55MM |
92033-1274 |
from US $5.60 |
||
|
92045
|
92045
92045-1222 BEARING-BALL,DAC3055Cベアリング(ボ-ル)，DAC3055C2RKCD3 |
92045-1222 |
from US $75.11 |
||
|
92049
|
92049
92049-1476 SEAL-OIL,MT038N1シ-ル(オイル)，MT038N1 |
92049-1476 |
from US $7.78 |
||
|
92049A
|
92049A
92049-1477 SEAL-OIL,SDD04 38 55シ-ル(オイル)，SDD04 38 55 8 |
92049-1477 |
from US $9.01 |
||
|
92092
|
92092
92092-1076 BUSHING-RUBBERブツシング(ラバ-) |
92092-1076 |
from US $22.61 |
||
|
92151
|
92151
92151-1101 BOLT,FLANGED,12X65.5ボルト，フランジ，12X65.5 |
92151-1101 |
US $10.89 |
||
|
92153
|
92153
92153-0579 BOLTボルト，フランジ，10X44 |
92153-0579 |
from US $1.56 |
||
|
92170
|
92170
92170-1720 CLAMP,HOSEクランプ，ホ-ス |
92170-1720 |
US $9.81 |
||
|
92200
|
92200
92200-1004 WASHER,12.3X23X2.3ワツシヤ，12.3X23X2.3 |
92200-1004 |
from US $2.85 |
||
|
92210
|
92210
92210-1066 NUT,35MMナツト，35MM |
92210-1066 |
from US $11.66 |
||
