Front brake Diagram Kawasaki KXF250 Tecate 4
- Model code
- KXF250-A1
- Engine Capacity
- 250
- Year
- 1987
- Sales region
- USA
- Stroke (2-stroke or 4-stroke)
- 2 stroke
- 2WD/4WD/AWD
- 2WD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
41080
|
41080
41080-1171 DISC,FRDisc,fr; |
41080-1171 |
from US $131.57 |
||
|
43041
|
43041
43041-1218 Caliper-assy,fr,lhCaliper-assy,fr,lh; |
43041-1218 |
US $425.21 |
||
| replacements | |||||
|
43041
|
43041
43041-1522 CALIPER-ASSY,FR,LHCaliper-assy,fr,lh; |
43041-1522 |
US $516.85 |
||
|
43041
|
43041
43041-1400 CALIPER-ASSY,FR,LHCaliper-assy,fr,lh; |
43041-1400 |
US $516.85 |
||
|
43041A
|
43041A
43041-1219 Caliper-assy,fr,rhCaliper-assy,fr,rh; |
43041-1219 |
US $425.21 |
||
| replacements | |||||
|
43041A
|
43041A
43080-5092-GN CALIPER-SUB-ASSY,FR,RCaliper-assy,fr,rh; |
43080-5092-GN |
US $402.34 |
||
|
43041A
|
43041A
43082-1163 PAD-ASSY-BRAKECaliper-assy,fr,rh; |
43082-1163 |
from US $65.06 |
||
|
43041A
|
43041A
43041-1523 CALIPER-ASSY,FR,RHCaliper-assy,fr,rh; |
43041-1523 |
US $516.85 |
||
|
43041A
|
43041A
43041-1401 CALIPER-ASSY,FR,RHCaliper-assy,fr,rh; |
43041-1401 |
US $516.85 |
||
|
43048
|
43048
43048-1008 PISTON-CALIPER |
43048-1008 |
US $33.25 |
||
| replacement | |||||
|
43048
|
43048
43020-1084 PISTON-COMP-BRAKE |
43020-1084 |
from US $44.13 |
||
|
43049
|
43049
43049-1016 PACKING |
43049-1016 |
US $10.39 |
||
| replacement | |||||
|
43049
|
43049
43049-1092 PACKING |
43049-1092 |
from US $6.97 |
||
|
43050
|
43050
43050-1040 PAD-BRAKE |
43050-1040 |
US $11.79 |
||
| replacement | |||||
|
43050
|
43050
43050-1169 PAD-BRAKE |
43050-1169 |
from US $12.44 |
||
|
43056
|
43056
43056-003
BLEEDER SET
|
43056-003 |
— | ||
| replacement | |||||
|
43056
|
43056
43085-001 BLEEDER SET |
43085-001 |
from US $14.69 |
||
|
43057
|
43057
43057-003 CAP,BREEDER |
43057-003 |
from US $3.01 |
||
|
43082
|
43082
43082-1067 PAD-ASSY-BRAKE |
43082-1067 |
US $55.80 |
||
| replacement | |||||
|
43082
|
43082
43082-1163 PAD-ASSY-BRAKE |
43082-1163 |
from US $65.06 |
||
|
49006
|
49006
49006-1053 BOOT,CALIPERBoot,piston seal; |
49006-1053 |
from US $16.63 |
||
|
49006A
|
49006A
49006-1054 BOOT,CALIPERBoot,caliper; |
49006-1054 |
from US $8.55 |
||
|
49006B
|
49006B
49006-1055 BOOT,CALIPERBoot,caliper; |
49006-1055 |
from US $4.91 |
||
|
92002
|
92002
92002-1736 BOLT,SOCKET,8X20Bolt,disc plate,8x20; |
92002-1736 |
from US $3.80 |
||
| replacement | |||||
|
92002
|
92002
92150-1760 BOLT,SOCKET,8X20Bolt,disc plate,8x20; |
92150-1760 |
from US $3.80 |
||
|
92002A
|
92002A
92002-1737 BOLT,FLANGED,8X13Bolt,flanged,8x13; |
92002-1737 |
from US $3.11 |
||
|
92081
|
92081
92081-1341 SPRING |
92081-1341 |
from US $9.35 |
||
