Front fender Diagram Kawasaki KXF250 Tecate 4
- Model code
- KXF250-A1
- Engine Capacity
- 250
- Year
- 1987
- Sales region
- USA
- Stroke (2-stroke or 4-stroke)
- 2 stroke
- 2WD/4WD/AWD
- 2WD
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
11012A
|
11012A
11012-1578-6W
CAP,RADIATOR,L.GREEN
Cap,radiator,l.green; |
11012-1578-6W |
— | ||
| replacement | |||||
|
11012A
|
11012A
11065-0260-6W
CAP,RADIATOR,L.GREEN
Cap,radiator,l.green; |
11065-0260-6W |
— | ||
|
14024A
|
14024A
14024-1412-6W
COVER,F FENDER,L GREN
Cover,front fender,l.green; |
14024-1412-6W |
— | ||
|
35004A
|
35004A
35004-1200-6W
FENDER FRONT,GREEN
Fender-front,l.green; |
35004-1200-6W |
— | ||
|
92002
|
92002
92002-1461
BOLT
Bolt,6x16; |
92002-1461 |
— | ||
| replacement | |||||
|
92002
|
92002
92150-1506 BOLTBolt,6x16; |
92150-1506 |
from US $3.01 |
||
|
92002A
|
92002A
92002-1462 BOLTBolt,6x25; |
92002-1462 |
US $5.98 |
||
| replacement | |||||
|
92002A
|
92002A
92150-1507 BOLTBolt,6x25; |
92150-1507 |
from US $3.33 |
||
|
92015
|
92015
92015-1678 NUTNut,clamp,6mm; |
92015-1678 |
from US $3.17 |
||
|
92027
|
92027
92027-1181 COLLARCollar,l=6.6; |
92027-1181 |
from US $3.60 |
||
| replacement | |||||
|
92027
|
92027
92152-1359 COLLARCollar,l=6.6; |
92152-1359 |
from US $3.96 |
||
