Muffler Diagram Kawasaki KXF250 Tecate 4
- Model code
- KXF250-A1
- Engine Capacity
- 250
- Year
- 1987
- Sales region
- USA
- Stroke (2-stroke or 4-stroke)
- 2 stroke
- 2WD/4WD/AWD
- 2WD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
11009
|
11009
11009-1253
GASKET,EXHAUST PIPE
Gasket,exhaust pipe; |
11009-1253 |
— | ||
| replacement | |||||
|
11009
|
11009
11009-1949 GASKET,EXHAUST PIPEGasket,exhaust pipe; |
11009-1949 |
from US $9.19 |
||
|
18002
|
18002
18002-1748
BODY-COMP-MUFFLER
|
18002-1748 |
— | ||
|
18002A
|
18002A
18002-1753
BODY,COMP-MUFFLER
|
18002-1753 |
— | ||
|
32069
|
32069
32069-1259
BRACKET-MUFFLER
|
32069-1259 |
— | ||
|
49099
|
49099
49099-1221
BAFFLE-PIPE MUFFLER
|
49099-1221 |
— | ||
|
92002
|
92002
92002-1461
BOLT
Bolt,6x16; |
92002-1461 |
— | ||
| replacement | |||||
|
92002
|
92002
92150-1506 BOLTBolt,6x16; |
92150-1506 |
from US $3.01 |
||
|
92015
|
92015
92015-1078
NUT,FLANGED,6MM
Nut,flanged,6mm; |
92015-1078 |
— | ||
| replacement | |||||
|
92015
|
92015
92210-0630 NUT,FLANGED,6MMNut,flanged,6mm; |
92210-0630 |
from US $0.95 |
||
|
92022
|
92022
92022-304 WASHER,PLAINWasher,6.2x11x1; |
92022-304 |
from US $2.53 |
||
|
92027
|
92027
92027-1981 COLLAR,MUFFLERCollar,muffler; |
92027-1981 |
from US $6.54 |
||
|
92075
|
92075
92075-1598 DAMPER,SIDE COVER |
92075-1598 |
from US $5.52 |
||
|
92075A
|
92075A
92075-1809 DAMPER,MUFFLERDamper,muffler; |
92075-1809 |
from US $4.98 |
||
|
92075B
|
92075B
92075-1891 DAMPER,MUFFLERDamper,muffler; |
92075-1891 |
from US $20.75 |
||
|
92093
|
92093
92093-1237 SEAL,MUFFLER CONNECTSeal,muffler connect; |
92093-1237 |
US $39.28 |
||
|
92144
|
92144
92144-1185 SPRING |
92144-1185 |
US $5.54 |
||
|
112
|
112
112B0610 BOLT-UPSET |
112B0610 |
US $0.29 |
||
| replacement | |||||
|
112
|
112
112BA0610 BOLT-UPSET |
112BA0610 |
from US $0.92 |
||
|
130
|
130
130G0825
BOLT-FLANGED,8X25
Bolt-flanged,8x25; |
130G0825 |
— | ||
| replacement | |||||
|
130
|
130
130BA0825 BOLT-FLANGED,8X25Bolt-flanged,8x25; |
130BA0825 |
from US $1.27 |
||
|
130A
|
130A
130G0855 BOLT-FLANGED,8X55Bolt-flanged,8x55; |
130G0855 |
from US $1.43 |
||
| replacement | |||||
|
130A
|
130A
130BA0855 BOLT-FLANGED,8X55Bolt-flanged,8x55; |
130BA0855 |
from US $1.43 |
||
|
187
|
187
187B0612
BOLT-UPSET-WSP
|
187B0612 |
— | ||
| replacement | |||||
|
187
|
187
187AA0612 BOLT-UPSET-WSP |
187AA0612 |
from US $1.11 |
||
|
671
|
671
671E2550 O RING,50MMO ring,50mm; |
671E2550 |
from US $12.04 |
||
