Crankcase Diagram Kawasaki KXF250 Tecate 4
- Model code
- KXF250-A2
- Engine Capacity
- 250
- Year
- 1988
- Sales region
- USA
- Stroke (2-stroke or 4-stroke)
- 2 stroke
- 2WD/4WD/AWD
- 2WD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
11009
|
11009
92065-058 GASKETGasket,10.5x16x1,drain plug; |
92065-058 |
from US $3.37 |
||
|
13206
|
13206
13206-1001 Guide,kickstarter |
13206-1001 |
US $6.10 |
||
| replacement | |||||
|
13206
|
13206
13206-1061 GUIDE-KICK |
13206-1061 |
from US $8.40 |
||
|
14001
|
14001
14001-5233
SET-CRANKCASE
|
14001-5233 |
— | ||
|
14069
|
14069
14069003 BREATHER |
14069003 |
from US $7.92 |
||
|
92001
|
92001
92001-1829 BOLT,W/WASHER,6X14Bolt,w/washer,6x14; |
92001-1829 |
from US $2.53 |
||
|
92002
|
92002
92002-1601 BOLT,RETURN SPRINGBolt,8x15; |
92002-1601 |
US $6.21 |
||
| replacement | |||||
|
92002
|
92002
92150-1467 BOLT,RETURN SPRINGBolt,8x15; |
92150-1467 |
from US $4.75 |
||
|
92002A
|
92002A
92002-1659 BOLTBolt,6x16; |
92002-1659 |
from US $3.01 |
||
|
92004
|
92004
92004-1032
STUD,10X65
Stud,10x65; |
92004-1032 |
— | ||
|
92004A
|
92004A
92004-1165
STUD,10X53
Stud,10x53; |
92004-1165 |
— | ||
|
92022
|
92022
92022-1865 WASHER |
92022-1865 |
US $2.50 |
||
|
92037
|
92037
92037-1318 CLAMP,HARNESSClamp,harness; |
92037-1318 |
from US $4.12 |
||
|
92043
|
92043
92042-007 PIN-DOWELPin,dowel,6.3x8x14; |
92042-007 |
from US $4.44 |
||
|
92045
|
92045
92045-036 BEARING,BALL,#6905Bearing-ball,#6905; |
92045-036 |
from US $21.38 |
||
|
92045A
|
92045A
92045-1010 Bearing,ball 626Bearing-ball,#626; |
92045-1010 |
US $6.43 |
||
| replacement | |||||
|
92045A
|
92045A
92045-1304 BEARING-BALLBearing-ball,#626; |
92045-1304 |
from US $12.21 |
||
|
92045B
|
92045B
92045-1115 BEARING-BALL,6205Bearing-ball,6205; |
92045-1115 |
US $24.09 |
||
|
92045C
|
92045C
92045-1116 BEARING-BALL,16008Bearing-ball,16008; |
92045-1116 |
US $30.80 |
||
|
92045D
|
92045D
92045-1134 BEARING-BALL,63/22T2CBearing-ball,63/22t2c3; |
92045-1134 |
from US $27.83 |
||
|
92045E
|
92045E
92045-1193 BEARING-BALL,6203SH2CBearing-ball,6203sh2c3; |
92045-1193 |
US $21.09 |
||
|
92045F
|
92045F
92045-1194 BEARING-BALLBearing-ball,tmb204c3; |
92045-1194 |
US $27.79 |
||
| replacement | |||||
|
92045F
|
92045F
92045-1041 BEARING-BALLBearing-ball,tmb204c3; |
92045-1041 |
from US $22.59 |
||
|
92045G
|
92045G
92045-1205 BEARING-BALL |
92045-1205 |
US $30.80 |
||
|
92049
|
92049
92049-1051 OIL SEAL,TCJ25457Seal-oil,tcj25457; |
92049-1051 |
from US $19.80 |
||
|
92049A
|
92049A
92050-033 OIL SEAL TB3040Seal-oil,tb3040; |
92050-033 |
from US $18.06 |
||
|
92049B
|
92049B
92051-005 OIL SEAL,TB13225.5Seal-oil,tb13225.5; |
92051-005 |
from US $6.57 |
||
|
92059
|
92059
92059-1953 TubeTube,6x9x630; |
92059-1953 |
US $9.76 |
||
| replacement | |||||
|
92059
|
92059
92059-1939 TUBETube,6x9x630; |
92059-1939 |
from US $10.43 |
||
|
92066
|
92066
92066-1241 DRAIN PLUGPlug,drain; |
92066-1241 |
from US $3.96 |
||
|
132
|
132
132G0612
BOLT-FLANGED-SMALL,6X
|
132G0612 |
— | ||
| replacement | |||||
|
132
|
132
132BA0612 BOLT-FLANGED-SMALL,6X |
132BA0612 |
from US $0.79 |
||
|
132A
|
132A
132G0616
BOLT-FLANGED-SMALL,6X
|
132G0616 |
— | ||
| replacement | |||||
|
132A
|
132A
132BA0616 BOLT-FLANGED-SMALL,6X |
132BA0616 |
from US $0.79 |
||
|
132B
|
132B
132G0650 BOLT-FLANGED-SMALL |
132G0650 |
US $25.20 |
||
| replacement | |||||
|
132B
|
132B
132BA0650 BOLT-FLANGED-SMALL |
132BA0650 |
from US $1.27 |
||
