Crankshaft/piston Diagram Kawasaki KXF250 Tecate 4
- Model code
- KXF250-A2
- Engine Capacity
- 250
- Year
- 1988
- Sales region
- USA
- Stroke (2-stroke or 4-stroke)
- 2 stroke
- 2WD/4WD/AWD
- 2WD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
13001
|
13001
13001-1246 PISTON-ENGINE |
13001-1246 |
US $123.42 |
||
|
13002
|
13002
13002-1068
PIN-PISTON
|
13002-1068 |
— | ||
| replacement | |||||
|
13002
|
13002
13002-1098 PIN-PISTON |
13002-1098 |
from US $19.80 |
||
|
13008
|
13008
13008-1091 RING-SET-PISTON |
13008-1091 |
US $105.86 |
||
|
13031A
|
13031A
13031-1267
Crankshaft-comp
|
13031-1267 |
— | ||
|
13033
|
13033
13033-1010 BEARING-SMALL ENDBearing-needle,kbk18x22x23.8x; |
13033-1010 |
from US $21.23 |
||
|
13034
|
13034
13034-1060 BEARING-BIG END,H24X3Bearing-big end,h24x32x19.8; |
13034-1060 |
US $55.87 |
||
|
13035
|
13035
13035-034
PIN,CRANK
|
13035-034 |
— | ||
|
13037B
|
13037B
13037-1335 CRANKSHAFT,LHCrankshaft,lh; |
13037-1335 |
US $399.49 |
||
|
13037C
|
13037C
13037-1336 CRANKSHAFT,RHCrankshaft,rh; |
13037-1336 |
US $295.25 |
||
|
13044
|
13044
13044-5042 SET-CONNECTING ROD |
13044-5042 |
US $188.60 |
||
|
13097
|
13097
13097-1189 GEAR-PRIMARY SPUR,22TGear-primary spur,22t; |
13097-1189 |
US $63.65 |
||
|
59051
|
59051
59051-1182 GEAR-SPUR,36TGear-spur,36t; |
59051-1182 |
US $77.96 |
||
|
92015
|
92015
92015-1176 NUT,16MMNut,16mm; |
92015-1176 |
US $4.52 |
||
|
92022
|
92022
92022-1356 WASHER,16.3X29X1.75Washer,16.3x29x1.75; |
92022-1356 |
from US $4.80 |
||
|
92026
|
92026
92026-1241
SPACER,24X42X1.6
Spacer,24x42x1.6; |
92026-1241 |
— | ||
| replacement | |||||
|
92026
|
92026
92026-1500 SPACER,24X42X1.6Spacer,24x42x1.6; |
92026-1500 |
US $5.07 |
||
|
92033
|
92033
92036-015 CIRCLIP-PISTON PINRing-snap,piston pin; |
92036-015 |
from US $3.33 |
||
