Rear fender Diagram Kawasaki KXF250 Tecate 4
- Model code
- KXF250-A2
- Engine Capacity
- 250
- Year
- 1988
- Sales region
- USA
- Stroke (2-stroke or 4-stroke)
- 2 stroke
- 2WD/4WD/AWD
- 2WD
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
32046
|
32046
32046-1294
BRACKET-SEAT
|
32046-1294 |
— | ||
|
35011A
|
35011A
35011-1399
STAY,REAR FENDER
Stay,rear fender; |
35011-1399 |
— | ||
|
35023
|
35023
35023-1191-6F
FENDER,RR,P WHITE
Fender-rear,p.white; |
35023-1191-6F |
— | ||
|
35023A
|
35023A
35023-1191-6W
FENDER-REAR.L GREEN
Fender-rear,l.green; |
35023-1191-6W |
— | ||
|
92015
|
92015
92015-1193
NUT,FLANGED,6MM
Nut,flanged,6mm; |
92015-1193 |
— | ||
| replacement | |||||
|
92015
|
92015
92015-1367 NUT,FLANGED,6MMNut,flanged,6mm; |
92015-1367 |
from US $3.01 |
||
|
92075
|
92075
92075-1153 DAMPER,SEATDamper,seat; |
92075-1153 |
from US $3.33 |
||
|
92075A
|
92075A
92075-1876 DAMPER |
92075-1876 |
from US $6.81 |
||
|
130
|
130
130G0814 BOLT-FLANGED,8X14Bolt-flanged,8x14; |
130G0814 |
from US $1.27 |
||
| replacement | |||||
|
130
|
130
130BA0814 BOLT-FLANGED,8X14Bolt-flanged,8x14; |
130BA0814 |
from US $0.95 |
||
