Front wheel (A04KA05CA) Diagram Polaris PREDATOR 50
- Model code
- A04KA05CA
- Year
- 2004
- Sales region
- General
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
0450393 Bearing |
0450393 |
US $30.01 |
||
|
2
|
2
0450389 Seal-oil * |
0450389 |
US $11.03 |
||
|
3
|
3
0451776
Wheel, front
|
0451776 |
— | ||
|
4
|
4
0450394 Nut-lock(10)* |
0450394 |
US $3.94 |
||
|
5
|
5
0450395 Pin-cotter (10) |
0450395 |
US $0.79 |
||
|
6
|
6
0450829 Cap-rubber * |
0450829 |
US $9.15 |
||
|
7
|
7
0450397 Washer(10) |
0450397 |
US $3.75 |
||
|
8
|
8
0451775 Tire-16x7-719x7-8; |
0451775 |
US $93.43 |
||
|
9
|
9
0450124 Bolt-hex wshr face(10) * |
0450124 |
US $3.26 |
||
|
10
|
10
0450401 Valve,rim |
0450401 |
US $6.11 |
||
|
11
|
11
0450391 Spacer,outer(10) * |
0450391 |
US $3.75 |
||
|
12
|
12
0450392
Bearing
|
0450392 |
— | ||
|
13
|
13
0450388
Drum, brake, front
|
0450388 |
— | ||
|
14
|
14
0450390 Spacer,inner(10) |
0450390 |
US $5.25 |
