Throttle body mounting (R06RF68AA) Diagram Polaris RANGER 700 6X6 EFI
- Model code
- R06RF68AA
- Year
- 2006
- Sales region
- General
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
7516822
Screw
|
7516822 |
— | ||
|
2
|
2
5134427
Cover, valve
|
5134427 |
— | ||
|
3
|
3
3021352 Asm-reed w/gasket |
3021352 |
US $24.61 |
||
|
4
|
4
5211776
Plate, reed, breather
|
5211776 |
— | ||
|
5
|
5
7517277 Screw |
7517277 |
US $3.94 |
||
|
6
|
6
5830122
Gasket, breather
|
5830122 |
— | ||
|
7
|
7
5432533
Cover,breather
|
5432533 |
— | ||
|
8
|
8
3021671 Sparkplug-champion rc7yc3 (4) |
3021671 |
US $5.90 |
||
|
9
|
9
1253527 Adaptor-throttle body |
1253527 |
US $54.18 |
||
|
10
|
10
7518488 Scr-m8x1,25x25,hxfl,cl8,8 zy3 |
7518488 |
US $4.73 |
||
|
11
|
11
7081193
Clamp-hose
|
7081193 |
— | ||
|
12
|
12
1203160
Asm-throttle body
|
1203160 |
— | ||
|
12
|
12
2410342 Sensor-throttle position keihnMust also order O-Ring; |
2410342 |
US $260.86 |
||
| replacement | |||||
|
12
|
12
1204715 Sensor-throttle position keihnMust also order O-Ring; |
1204715 |
US $260.86 |
||
|
12
|
12
5413812 O-ring 10,5mm x 1mm v75,75dUsed w/2410342; |
5413812 |
US $2.28 |
||
|
13
|
13
7080236 Clamp-hose |
7080236 |
US $2.45 |
||
|
14
|
14
8350018
Tubing
|
8350018 |
— | ||
|
15
|
15
7052038 Valve, check |
7052038 |
US $9.15 |
||
|
16
|
16
7517384 Screw,sochd,m6x20 |
7517384 |
US $7.68 |
||
|
17
|
17
2410720 Sensor-crank position |
2410720 |
from US $91.60 |
||
|
18
|
18
5412632
Seal-valve cover
|
5412632 |
— | ||
