Control panel (A02BG38CA) Diagram Polaris SCRAMBLER 400 4X4
- Model code
- A02BG38CA
- Year
- 2002
- Sales region
- General
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
5433534 Key cover-keyswitch |
5433534 |
US $19.69 |
||
|
2
|
2
4010390
Switch, ignition
|
4010390 |
— | ||
| replacement | |||||
|
2
|
2
4012164 Switch-ignition,keystart,mt sl |
4012164 |
US $125.49 |
||
|
2
|
2
5433733 Nut,ignition switch |
5433733 |
US $14.09 |
||
|
2
|
2
4010278 Key blank (20/21/67/68) seriesNOTE: Ignition key blank may be ordered by using the four digit number on the key.; |
4010278 |
US $12.81 |
||
|
3
|
3
5434127 Panel-control,outer |
5434127 |
US $24.43 |
||
|
4
|
4
7081008 Cable-choke,friction,40" |
7081008 |
US $70.89 |
||
|
5
|
5
5434128
Panel-control,inner
|
5434128 |
— | ||
|
6
|
6
7080922 Nut,choke,m24x1,5 thd,m29 hex |
7080922 |
US $4.73 |
||
|
7
|
7
4010563
Panel-indicator,o/h/n/r
|
4010563 |
— | ||
