Control panel (A04BG50AA/FA) Diagram Polaris SCRAMBLER 500 4X4
- Model code
- A04BG50AA/FA
- Year
- 2004
- Sales region
- General
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
5433534 Key cover-keyswitch |
5433534 |
US $19.69 |
||
|
2
|
2
4011002
Switch, key
|
4011002 |
— | ||
|
2
|
2
5433733 Nut,ignition switch |
5433733 |
US $14.09 |
||
|
2
|
2
4010278 Key blank (20/21/67/68) seriesNOTE: Ignition key blank may be ordered by using the four digit number on the key.; |
4010278 |
US $12.81 |
||
|
3
|
3
5434127 Panel-control,outer |
5434127 |
US $24.43 |
||
|
4
|
4
7081007
Cable, choke
If built before 8/11/03; |
7081007 |
— | ||
|
4
|
4
7081177 Cable-choke,friction,26"If built after 8/11/03; |
7081177 |
US $31.52 |
||
|
5
|
5
5434128
Panel-control,inner
|
5434128 |
— | ||
|
6
|
6
7080922 Nut,choke,m24x1,5 thd,m29 hex |
7080922 |
US $4.73 |
||
|
7
|
7
4010416 Bulb-indicator,hobbs |
4010416 |
US $10.83 |
||
|
7
|
7
4010315
Panel, indicator light, 3 position
|
4010315 |
— | ||
| replacement | |||||
|
7
|
7
4010459
Panel-indicator,svc,std pvt
|
4010459 |
— | ||
