Front cab (A00CK42AA) Diagram Polaris XPEDITION 425
- Model code
- A00CK42AB
- Year
- 2000
- Sales region
- General
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
5811491 Foil-rh |
5811491 |
US $4.34 |
||
|
2
|
2
5810996 Foil,foam |
5810996 |
US $56.14 |
||
|
3
|
3
2632084-282
Panel asm/foam,lh,xped,d,dune
A00CK42AA; |
2632084-282 |
— | ||
|
3
|
3
2632084-136
Panel/foam,lh,xped,por red,asm.
A00CK42AB; |
2632084-136 |
— | ||
|
3
|
3
2632068-282 Panel/foil,rh,xped,d,duneA00CK42AA; |
2632068-282 |
US $131.97 |
||
|
3
|
3
2632068-136 Panel/foil,rh,xped,por redA00CK42AB; |
2632068-136 |
US $117.20 |
||
|
4
|
4
7512232 Bolt(10)10; |
7512232 |
US $26.30 |
||
|
5
|
5
5811801 Foam,front |
5811801 |
US $5.64 |
||
|
6
|
6
5432088-282 Cover-front,desert duneA00CK42AA; |
5432088-282 |
US $122.12 |
||
|
6
|
6
5432088-136
Cover,front,p,red
A00CK42AB; |
5432088-136 |
— | ||
|
7
|
7
7670085 Clip,spring(10)10; |
7670085 |
US $1.77 |
||
|
8
|
8
2632133-282
Asm-cab,foam,front,desert dune
A00CK42AA; |
2632133-282 |
— | ||
| replacement | |||||
|
8
|
8
2632301-282
Cab,foam/front,desert dune
A00CK42AA; |
2632301-282 |
— | ||
|
8
|
8
2632133-136
Cab,foam,front,porche red
A00CK42AB; |
2632133-136 |
— | ||
| replacement | |||||
|
8
|
8
2632301-136
Cab,foam/front,porche red,asm,
A00CK42AB; |
2632301-136 |
— | ||
|
9
|
9
7670057 Nut, speed(10) *10; |
7670057 |
US $2.63 |
||
|
10
|
10
7670009 Palnut(10)10; |
7670009 |
US $0.79 |
||
|
11
|
11
7661645 Rivet(50) *50; |
7661645 |
US $1.89 |
||
|
12
|
12
5431798
Mudguard,lh,frt.blk.
|
5431798 |
— | ||
| replacement | |||||
|
12
|
12
5431798-070 Guard-mudflap,front,black,lh |
5431798-070 |
US $56.14 |
||
|
12
|
12
5431799
Mudguard,rh,frt.blk.
|
5431799 |
— | ||
| replacement | |||||
|
12
|
12
5431799-070 Guard-mudflap,front,black,rh |
5431799-070 |
US $56.14 |
||
|
13
|
13
7541925
Nut, nylok 10-24 y
10; |
7541925 |
— | ||
|
14
|
14
7555792 Washer10; |
7555792 |
US $2.45 |
||
|
15
|
15
7512085
Screw
10; |
7512085 |
— | ||
| replacement | |||||
|
15
|
15
7511989
Screw
10; |
7511989 |
— | ||
|
16
|
16
7555931
Washer
10; |
7555931 |
— | ||
| replacement | |||||
|
16
|
16
7558221 Washer(10)10; |
7558221 |
US $0.79 |
||
|
17
|
17
7542122 Nut-nylok(10)10; |
7542122 |
US $26.30 |
||
|
18
|
18
7670088 Clip,plastic dart,nylon10; |
7670088 |
US $2.45 |
||
|
19
|
19
5811489
Shield,deflector
|
5811489 |
— | ||
| replacement | |||||
|
19
|
19
5811917 Shield-deflector |
5811917 |
US $9.15 |
||
