Cylinder Diagram Yamaha BADGER
- Model code
- YFM80T
- Engine Capacity
- 79
- Year
- 1987
- Sales region
- USA
- 2WD/4WD/AWD
- 2WD
- Model
- Badger
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
35T-11110-01-00 Cylinder Head Assy |
35T-11110-01-00 |
from US $465.12 |
||
|
2
|
2
22F-11134-10-00 Guide, Valve 2 |
22F-11134-10-00 |
from US $35.72 |
||
|
3
|
3
93440-10109-00 Circlip |
93440-10109-00 |
from US $1.34 |
||
|
4
|
4
22F-14651-00-00 Bolt, Stud |
22F-14651-00-00 |
from US $3.54 |
||
|
5
|
5
22F-11185-01-00 Cover, Cylinder Head Side 3 |
22F-11185-01-00 |
from US $22.99 |
||
| replacement | |||||
|
5
|
5
22F-11185-10-00 Cover, Cylinder Head Side 3 |
22F-11185-10-00 |
from US $23.94 |
||
|
6
|
6
93210-63556-00 O-Ring |
93210-63556-00 |
from US $2.32 |
||
|
7
|
7
22F-11186-00-00 Cover, Cylinder Head Side 2 |
22F-11186-00-00 |
from US $12.89 |
||
| replacement | |||||
|
7
|
7
22F-11186-10-00 Cover, Cylinder Head Side 2 |
22F-11186-10-00 |
from US $10.26 |
||
|
8
|
8
93210-44704-00 O-Ring |
93210-44704-00 |
from US $1.42 |
||
|
9
|
9
985-03060-14-00
Screw, Pan Head
|
985-03060-14-00 |
— | ||
| replacement | |||||
|
9
|
9
98507-06014-00 Screw, Pan Head |
98507-06014-00 |
from US $1.07 |
||
|
10
|
10
90201-066F0-00 Washer, Plate |
90201-066F0-00 |
from US $1.56 |
||
|
11
|
11
90176-06041-00 Nut, Crown (21G) |
90176-06041-00 |
from US $3.40 |
||
|
12
|
12
NGK-C7HSA-00-00 C7Hsa Ngk 10Pk |
NGK-C7HSA-00-00 |
US $4.23 |
||
| replacements | |||||
|
12
|
12
C7H-SA000-00-00 B5ES NGK SPLUG 4PK |
C7H-SA000-00-00 |
US $16.84 |
||
|
12
|
12
NGK-CR7HS-00-00
Plug Spark
|
NGK-CR7HS-00-00 |
— | ||
|
13
|
13
55X-11181-00-00 Gasket, Cylinder Head 1 |
55X-11181-00-00 |
from US $16.15 |
||
|
14
|
14
995-10080-12-00
Pin, Dowel
|
995-10080-12-00 |
— | ||
| replacement | |||||
|
14
|
14
91808-12024-00 Pin, Dowel |
91808-12024-00 |
from US $1.84 |
||
|
15
|
15
95021-06085-00 Bolt, Flange |
95021-06085-00 |
from US $1.56 |
||
| replacement | |||||
|
15
|
15
95027-06085-00 Bolt, Flange |
95027-06085-00 |
from US $1.56 |
||
|
16
|
16
22K-11311-02-00
Cylinder 1
|
22K-11311-02-00 |
— | ||
|
17
|
17
4EM-11351-00-00 Gasket, Cylinder |
4EM-11351-00-00 |
from US $6.09 |
||
| replacement | |||||
|
17
|
17
22F-11351-01-00 Gasket, Cylinder |
22F-11351-01-00 |
from US $3.64 |
||
