Guard Diagram Yamaha GRIZZLY 350 Grizzly 350 4WD
- Model code
- 4S28
- Engine Capacity
- 348
- Year
- 2008
- Sales region
- Europe (General) (010)
- Colour
- Deep Purplish Blue Solid E (DPBSE; 0583)
- Power
- 21 hp
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- 2WD/4WD/AWD
- 4WD
- Model
- Grizzly 350 4WD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
01
|
01
1D9-F845N-01-00
Bar, Carry Front
|
1D9-F845N-01-00 |
— | ||
|
02
|
02
5KM-2482H-01-00 Cap |
5KM-2482H-01-00 |
from US $3.83 |
||
|
03
|
03
95812-08012-00 Bolt, Flange |
95812-08012-00 |
from US $1.07 |
||
| replacement | |||||
|
03
|
03
95817-08012-00 Bolt, Flange |
95817-08012-00 |
from US $1.07 |
||
|
04
|
04
1D9-F8415-00-00 Damper 1 |
1D9-F8415-00-00 |
US $92.45 |
||
|
05
|
05
97702-60016-00 Screw, Tapping |
97702-60016-00 |
from US $1.56 |
||
|
06
|
06
1D9-F8416-00-00 Damper 2 |
1D9-F8416-00-00 |
US $100.22 |
||
|
07
|
07
97702-60016-00 Screw, Tapping |
97702-60016-00 |
from US $1.56 |
||
|
08
|
08
5TE-F4841-01-00 Carrier, Front |
5TE-F4841-01-00 |
US $357.66 |
||
|
09
|
09
95812-08012-00 Bolt, Flange |
95812-08012-00 |
from US $1.07 |
||
| replacement | |||||
|
09
|
09
95817-08012-00 Bolt, Flange |
95817-08012-00 |
from US $1.07 |
||
|
10
|
10
5TE-F4842-10-00 Carrier, Rear |
5TE-F4842-10-00 |
US $288.56 |
||
|
11
|
11
95812-08012-00 Bolt, Flange |
95812-08012-00 |
from US $1.07 |
||
| replacement | |||||
|
11
|
11
95817-08012-00 Bolt, Flange |
95817-08012-00 |
from US $1.07 |
||
