Oil pump Diagram Yamaha GRIZZLY 350 Grizzly 350 4WD
- Model code
- YFM35FGDR
- Engine Capacity
- 348
- Year
- 2013
- Sales region
- USA
- Power
- 21 hp
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- 2WD/4WD/AWD
- 4WD
- Model
- Grizzly 350 4WD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
5UH-13300-00-00 Oil Pump Assy |
5UH-13300-00-00 |
from US $58.86 |
||
|
2
|
2
5UH-13329-00-00 Gasket, Pump Cover |
5UH-13329-00-00 |
from US $1.66 |
||
|
3
|
3
95022-06025-00 Bolt, Flange |
95022-06025-00 |
from US $1.42 |
||
|
4
|
4
5UH-13327-00-00 Cover, Pump Gear |
5UH-13327-00-00 |
US $3.26 |
||
|
5
|
5
95022-06012-00 Bolt, Flange |
95022-06012-00 |
from US $1.07 |
||
|
6
|
6
5UH-13411-00-00 Strainer, Oil |
5UH-13411-00-00 |
from US $6.62 |
||
|
7
|
7
90105-05016-00 Bolt, Flange |
90105-05016-00 |
from US $1.70 |
||
|
8
|
8
93505-16006-00 Ball |
93505-16006-00 |
from US $1.70 |
||
|
9
|
9
905-01101-A7-00 Spring, Compression |
905-01101-A7-00 |
from US $1.98 |
||
|
10
|
10
5UH-1319K-00-00 Plate |
5UH-1319K-00-00 |
US $1.46 |
||
|
11
|
11
5GH-13440-20-00
Element Assy, Oil Cleaner
|
5GH-13440-20-00 |
— | ||
| replacement | |||||
|
11
|
11
5GH-13440-80-00 Element Assy, Oil Cleaner |
5GH-13440-80-00 |
from US $21.50 |
||
|
12
|
12
904-01200-08-00 Bolt, Union |
904-01200-08-00 |
from US $9.35 |
||
|
13
|
13
1NS-13132-00-00 Joint |
1NS-13132-00-00 |
US $34.11 |
||
|
14
|
14
904-30140-43-00 Gasket |
904-30140-43-00 |
from US $1.13 |
||
|
15
|
15
1NS-E2405-00-00 Blower Assy |
1NS-E2405-00-00 |
US $318.93 |
||
| replacement | |||||
|
15
|
15
1NS-E2405-01-00 BLOWER ASSY |
1NS-E2405-01-00 |
US $302.15 |
||
|
16
|
16
1NS-E3480-00-00 Element, Oil Cooler |
1NS-E3480-00-00 |
from US $419.29 |
||
|
17
|
17
1NS-E3577-00-00 Clip |
1NS-E3577-00-00 |
US $9.59 |
||
|
18
|
18
1NS-E3573-00-00 Bolt 1 |
1NS-E3573-00-00 |
US $7.63 |
||
|
19
|
19
1NS-E3464-10-00 Hose, Oil 1 |
1NS-E3464-10-00 |
US $36.50 |
||
|
20
|
20
1NS-E3465-10-00 Hose, Oil 2 |
1NS-E3465-10-00 |
US $38.27 |
||
|
21
|
21
90467-150A0-00 Clip |
90467-150A0-00 |
from US $4.30 |
||
|
22
|
22
904-80152-35-00
Grommet
|
904-80152-35-00 |
— | ||
| replacement | |||||
|
22
|
22
90480-12475-00 Grommet(2Gh) |
90480-12475-00 |
from US $1.35 |
||
|
23
|
23
90387-06113-00 Collar |
90387-06113-00 |
from US $1.56 |
||
|
24
|
24
90209-06012-00 Washer |
90209-06012-00 |
from US $1.84 |
||
|
25
|
25
95812-06020-00 Bolt, Flange |
95812-06020-00 |
from US $1.13 |
||
| replacement | |||||
|
25
|
25
95817-06020-00 Bolt, Flange |
95817-06020-00 |
from US $1.13 |
||
