Front fender Diagram Yamaha KODIAK 400 Kodiak 400 2WD
- Model code
- YFM400AR
- Engine Capacity
- 401
- Year
- 2003
- Sales region
- USA
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- 2WD/4WD/AWD
- 2WD
- Model
- Kodiak 400 2WD
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
5ND-F1500-00-00
Front Fender Assy
for Color ROMANTIQUE ROUGE RTR / 00TR |
5ND-F1500-00-00 |
— | ||
|
1
|
1
5ND-F1500-10-00
Front Fender Assy
for Color PASTEL DEEP GREEN PDG / 00K0 |
5ND-F1500-10-00 |
— | ||
|
1
|
1
5ND-F1500-20-00
Front Fender Assy
for Color DARK GRAYISH YELLOW SOLID 1 DNYS1 / 0598 |
5ND-F1500-20-00 |
— | ||
|
2
|
2
90119-06060-00 Bolt, With Washer |
90119-06060-00 |
US $1.35 |
||
| replacement | |||||
|
2
|
2
90119-06226-00 Bolt, With Washer |
90119-06226-00 |
from US $1.34 |
||
|
3
|
3
90119-06060-00 Bolt, With Washer |
90119-06060-00 |
US $1.35 |
||
| replacement | |||||
|
3
|
3
90119-06226-00 Bolt, With Washer |
90119-06226-00 |
from US $1.34 |
||
|
4
|
4
90119-06060-00 Bolt, With Washer |
90119-06060-00 |
US $1.35 |
||
| replacement | |||||
|
4
|
4
90119-06226-00 Bolt, With Washer |
90119-06226-00 |
from US $1.34 |
||
|
5
|
5
5ND-F1575-00-00 Seal 1 |
5ND-F1575-00-00 |
US $10.66 |
||
|
6
|
6
5ND-F3391-00-00
Panel, Front
|
5ND-F3391-00-00 |
— | ||
| replacement | |||||
|
6
|
6
5ND-F3391-02-00
Panel, Front
|
5ND-F3391-02-00 |
— | ||
|
7
|
7
902-69068-00-00 Rivet |
902-69068-00-00 |
from US $2.69 |
||
|
8
|
8
5ND-F8309-00-00
Grille, Front
|
5ND-F8309-00-00 |
— | ||
|
9
|
9
5FU-F175B-01-00 Tuning Fork Mark |
5FU-F175B-01-00 |
from US $35.78 |
||
|
10
|
10
90110-06007-00 Bolt, Hexagon Socket Head |
90110-06007-00 |
from US $1.70 |
||
| replacement | |||||
|
10
|
10
90110-06102-00 Bolt, Hexagon Socket Head |
90110-06102-00 |
from US $1.70 |
||
|
11
|
11
90119-06060-00 Bolt, With Washer |
90119-06060-00 |
US $1.35 |
||
| replacement | |||||
|
11
|
11
90119-06226-00 Bolt, With Washer |
90119-06226-00 |
from US $1.34 |
||
|
12
|
12
90110-06202-00 Bolt, Hexagon Socket Head |
90110-06202-00 |
from US $1.70 |
||
|
13
|
13
90387-067V1-00 Collar(3Kj) |
90387-067V1-00 |
from US $1.70 |
||
| replacement | |||||
|
13
|
13
90387-068J5-00 Collar |
90387-068J5-00 |
from US $1.70 |
||
|
14
|
14
5GH-28349-00-00 Cap |
5GH-28349-00-00 |
from US $5.38 |
||
|
15
|
15
5TE-F837L-00-00 Panel, Console 1 |
5TE-F837L-00-00 |
US $121.66 |
||
| replacement | |||||
|
15
|
15
5TE-F837L-02-00 Panel, Console 1 |
5TE-F837L-02-00 |
US $119.83 |
||
|
16
|
16
902-69068-00-00 Rivet |
902-69068-00-00 |
from US $2.69 |
||
