Exhaust Diagram Yamaha TERRA PRO Terra Pro
- Model code
- YFP350U
- Engine Capacity
- 349
- Year
- 1988
- Sales region
- USA
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- 2WD/4WD/AWD
- 2WD
- Model
- Terra Pro
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
2NL-14611-00-00
Pipe, Exhaust L
|
2NL-14611-00-00 |
— | ||
|
2
|
2
1UY-14612-01-00 Nut, Ring |
1UY-14612-01-00 |
US $3.35 |
||
|
3
|
3
2NL-14711-00-00
Muffler L
|
2NL-14711-00-00 |
— | ||
|
4
|
4
1JK-14714-00-00
Gasket, Muffler
|
1JK-14714-00-00 |
— | ||
| replacement | |||||
|
4
|
4
3YF-14714-00-00 Gasket, Muffler |
3YF-14714-00-00 |
from US $19.13 |
||
|
5
|
5
970-16080-25-00
Boulon
|
970-16080-25-00 |
— | ||
| replacement | |||||
|
5
|
5
97017-08025-00 Bolt |
97017-08025-00 |
from US $1.21 |
||
|
6
|
6
929-06086-00-00
Washer
|
929-06086-00-00 |
— | ||
| replacement | |||||
|
6
|
6
929-07086-00-00 Washer, Plate |
929-07086-00-00 |
from US $1.21 |
||
|
7
|
7
2NL-14718-00-00 Protector, Muff 1 |
2NL-14718-00-00 |
US $35.06 |
||
|
8
|
8
98906-06012-00 Screw, Bind |
98906-06012-00 |
from US $1.42 |
||
| replacement | |||||
|
8
|
8
98907-06012-00 Screw, Bind |
98907-06012-00 |
from US $1.42 |
||
|
9
|
9
30X-14766-00-00
Washer, Protector
|
30X-14766-00-00 |
— | ||
| replacement | |||||
|
9
|
9
5RB-14766-00-00 Washer, Protector |
5RB-14766-00-00 |
US $2.55 |
||
|
10
|
10
90206-06090-00 Washer, Wave(3Rw) J |
90206-06090-00 |
from US $1.34 |
||
|
11
|
11
59V-14752-00-00 Pipe, Outlet |
59V-14752-00-00 |
from US $114.26 |
||
|
12
|
12
970-11060-10-00
Bolt
|
970-11060-10-00 |
— | ||
| replacement | |||||
|
12
|
12
97017-06010-00 Bolt |
97017-06010-00 |
from US $1.34 |
||
|
13
|
13
929-06066-00-00
Washer
|
929-06066-00-00 |
— | ||
| replacement | |||||
|
13
|
13
92907-06600-00 Washer, Plate |
92907-06600-00 |
from US $1.04 |
||
|
14
|
14
90101-06576-00 Bolt |
90101-06576-00 |
from US $1.70 |
||
|
15
|
15
2NL-14728-00-00
Protecter, Muff 2
|
2NL-14728-00-00 |
— | ||
|
16
|
16
2NL-14738-00-00
Protector, Mufflr 3
|
2NL-14738-00-00 |
— | ||
|
17
|
17
2NL-14748-00-00
Protect, Muffler 4
|
2NL-14748-00-00 |
— | ||
|
18
|
18
90430-38054-00 Gasket, Exhaust Pipe |
90430-38054-00 |
from US $6.66 |
||
| replacement | |||||
|
18
|
18
3GD-14613-00-00 Gasket, Exhaust Pipe |
3GD-14613-00-00 |
from US $5.96 |
||
|
19
|
19
901-79064-99-00
Nut
|
901-79064-99-00 |
— | ||
| replacement | |||||
|
19
|
19
90179-06500-00 Nut |
90179-06500-00 |
from US $2.13 |
||
|
20
|
20
95811-08016-00 Bolt, Flange |
95811-08016-00 |
from US $1.07 |
||
| replacements | |||||
|
20
|
20
901-0508X-15-00
Blt,hex,1/4-20X5/8
|
901-0508X-15-00 |
— | ||
|
20
|
20
958-17080-16-00 Bolt, Flange |
958-17080-16-00 |
from US $1.07 |
||
|
21
|
21
90201-08326-00 Washer (853) |
90201-08326-00 |
from US $1.66 |
||
| replacement | |||||
|
21
|
21
90201-08877-00 Washer (853) |
90201-08877-00 |
from US $1.28 |
||
|
22
|
22
929-90066-00-00 Washer, Plain (646) |
929-90066-00-00 |
from US $1.07 |
||
|
23
|
23
929-95061-00-00 Washer, Spring |
929-95061-00-00 |
from US $0.99 |
||
