Rear brake caliper Diagram Yamaha TRI-MOTO Tri-Moto 175
- Model code
- YT175J
- Engine Capacity
- 175
- Year
- 1982
- Sales region
- USA
- Stroke (2-stroke or 4-stroke)
- 2 stroke
- 2WD/4WD/AWD
- 2WD
- Model
- Tri-Moto 175
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
5V6-25711-00-00
Disc, Brake
|
5V6-25711-00-00 |
— | ||
|
2
|
2
5V6-25731-00-00 Body, Caliper 1 |
5V6-25731-00-00 |
from US $37.16 |
||
|
3
|
3
5V6-25741-00-00
Body, Caliper 2
|
5V6-25741-00-00 |
— | ||
|
4
|
4
2HR-W0045-00-00
Brake Pad Kit
|
2HR-W0045-00-00 |
— | ||
| replacement | |||||
|
4
|
4
2HR-W0045-09-00 Brake Pad Kit |
2HR-W0045-09-00 |
from US $49.82 |
||
|
5
|
5
3X3-25728-00-00
Cam
|
3X3-25728-00-00 |
— | ||
|
6
|
6
90101-08536-00 Bolt, Head With Hole |
90101-08536-00 |
from US $6.57 |
||
| replacement | |||||
|
6
|
6
90103-08026-00 Bolt, Head With Hole |
90103-08026-00 |
from US $7.23 |
||
|
7
|
7
953-33086-00-00 Nut |
953-33086-00-00 |
from US $1.42 |
||
| replacement | |||||
|
7
|
7
997-80086-00-00 Nut, Hex |
997-80086-00-00 |
from US $1.59 |
||
|
8
|
8
90201-08730-00 Washer, Plate |
90201-08730-00 |
from US $1.70 |
||
| replacement | |||||
|
8
|
8
90201-087F0-00 Washer, Plate |
90201-087F0-00 |
from US $1.70 |
||
|
9
|
9
3X3-25726-01-00
Lever, Brake
|
3X3-25726-01-00 |
— | ||
|
10
|
10
3X3-25736-00-00
Hook, Spring
|
3X3-25736-00-00 |
— | ||
|
11
|
11
5V6-25733-00-00 Plate, Back UpUP |
5V6-25733-00-00 |
from US $14.31 |
||
| replacement | |||||
|
11
|
11
J45-25733-00-00 Plate, Back UpUP |
J45-25733-00-00 |
from US $14.31 |
||
|
12
|
12
931-02152-12-00 Oil Seal |
931-02152-12-00 |
from US $4.30 |
||
|
13
|
13
970-22100-85-00
Bolt, Hexagon
|
970-22100-85-00 |
— | ||
| replacement | |||||
|
13
|
13
970-17100-85-00
BOLT (84K)
|
970-17100-85-00 |
— | ||
|
14
|
14
929-90106-00-00 Washer, Plate |
929-90106-00-00 |
from US $1.07 |
||
|
15
|
15
92990-10100-00 Ybs67-10 Washer, Spring |
92990-10100-00 |
from US $1.34 |
||
|
16
|
16
95380-10600-00 Ecrou |
95380-10600-00 |
from US $2 |
||
|
17
|
17
90506-16215-00 Spring, Tension |
90506-16215-00 |
from US $5.18 |
||
|
18
|
18
5V6-25715-00-00
Cover 1
|
5V6-25715-00-00 |
— | ||
|
19
|
19
5V6-25716-00-00
Cover 2
|
5V6-25716-00-00 |
— | ||
|
20
|
20
902-69060-26-00
Rivet, Spec''l Shape
|
902-69060-26-00 |
— | ||
|
21
|
21
985-03060-14-00
Screw, Pan Head
|
985-03060-14-00 |
— | ||
| replacement | |||||
|
21
|
21
98507-06014-00 Screw, Pan Head |
98507-06014-00 |
from US $1.07 |
||
|
22
|
22
929-95061-00-00 Washer, Spring |
929-95061-00-00 |
from US $0.99 |
||
|
23
|
23
929-01066-00-00
Washer
|
929-01066-00-00 |
— | ||
| replacements | |||||
|
23
|
23
929-90066-00-00 Washer, Plain (646) |
929-90066-00-00 |
from US $1.07 |
||
|
23
|
23
90201-061A5-00 Washer, Plate (4H7) |
90201-061A5-00 |
from US $1.84 |
||
|
23
|
23
92907-06600-00 Washer, Plate |
92907-06600-00 |
from US $1.04 |
||
