Side cover Diagram Yamaha TRI-MOTO Tri-Moto 200
- Model code
- YTM200ERN
- Engine Capacity
- 200
- Year
- 1985
- Sales region
- USA
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- 2WD/4WD/AWD
- 2WD
- Model
- Tri-Moto 200
Difficulties in parts search?
Parts list
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
21V-21711-00-00
Cover, Side 1
COMPETITION YELLOW |
21V-21711-00-00 |
— | ||
|
2
|
2
21V-2172E-00-00
Stay, Side Cover 1
|
21V-2172E-00-00 |
— | ||
|
3
|
3
970-13060-12-00
Bolt
|
970-13060-12-00 |
— | ||
| replacement | |||||
|
3
|
3
970-80060-12-00 Bolt |
970-80060-12-00 |
from US $1.98 |
||
|
4
|
4
929-95061-00-00 Washer, Spring |
929-95061-00-00 |
from US $0.99 |
||
|
5
|
5
90201-061A5-00 Washer, Plate (4H7) |
90201-061A5-00 |
from US $1.84 |
||
|
6
|
6
904-80103-43-00
Grommet
|
904-80103-43-00 |
— | ||
|
7
|
7
90159-06016-00 Screw, With Washer |
90159-06016-00 |
from US $1.56 |
||
|
8
|
8
90480-01401-00 Grommet (41Y)41Y |
90480-01401-00 |
from US $2.83 |
||
|
9
|
9
52G-21781-00-00
Emblem 1
|
52G-21781-00-00 |
— | ||
|
10
|
10
52G-21782-00-00
Emblem 2
|
52G-21782-00-00 |
— | ||
