Side cover - tool Diagram Yamaha TRI-MOTO Tri-Moto 200
- Model code
- YTM200L
- Engine Capacity
- 200
- Year
- 1984
- Sales region
- USA
- Stroke (2-stroke or 4-stroke)
- 4 stroke
- 2WD/4WD/AWD
- 2WD
- Model
- Tri-Moto 200
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
21V-21711-00-00
Cover, Side 1
U.R.COMP. YEL |
21V-21711-00-00 |
— | ||
|
2
|
2
21V-21711-50-00
Cover, Side 1
U.R.SKY BLUE |
21V-21711-50-00 |
— | ||
|
2
|
2
21V-2172E-00-00
Stay, Side Cover 1
|
21V-2172E-00-00 |
— | ||
|
3
|
3
970-13060-12-00
Bolt
661 |
970-13060-12-00 |
— | ||
| replacement | |||||
|
3
|
3
970-80060-12-00 Bolt661 |
970-80060-12-00 |
from US $1.98 |
||
|
4
|
4
929-95061-00-00 Washer, Spring |
929-95061-00-00 |
from US $0.99 |
||
|
5
|
5
929-01066-00-00
Washer
|
929-01066-00-00 |
— | ||
| replacements | |||||
|
5
|
5
929-90066-00-00 Washer, Plain (646) |
929-90066-00-00 |
from US $1.07 |
||
|
5
|
5
90201-061A5-00 Washer, Plate (4H7) |
90201-061A5-00 |
from US $1.84 |
||
|
5
|
5
92907-06600-00 Washer, Plate |
92907-06600-00 |
from US $1.04 |
||
|
6
|
6
904-80103-43-00
Grommet
|
904-80103-43-00 |
— | ||
|
7
|
7
90159-06016-00 Screw, With Washer |
90159-06016-00 |
from US $1.56 |
||
|
8
|
8
90480-01401-00 Grommet (41Y)41Y YTM200L |
90480-01401-00 |
from US $2.83 |
||
|
9
|
9
21V-21781-30-00
Emblem 1
U.R. FOR CPYYTM200L |
21V-21781-30-00 |
— | ||
|
9
|
9
21V-21781-50-00
Emblem 1
U.R. FOR SYBYTM200L |
21V-21781-50-00 |
— | ||
|
10
|
10
21V-21782-50-00
Emblem 2
U.R. FOR SYBYTM200L |
21V-21782-50-00 |
— | ||
|
10
|
10
21V-21782-30-00
Emblem 2
U.R. FOR CPYYTM200L |
21V-21782-30-00 |
— | ||
|
11
|
11
21V-21783-50-00
Emblem 3
U.R. FOR SYBYTM200L |
21V-21783-50-00 |
— | ||
|
11
|
11
21V-21783-30-00
Emblem 3
U.R. FOR CPYYTM200L |
21V-21783-30-00 |
— | ||
|
12
|
12
59V-28100-00-00
Tool Kit (24W-28100-00)
24W-28100-00 YTM200L |
59V-28100-00-00 |
— | ||
|
13
|
13
21V-21376-00-00 Band, Tool |
21V-21376-00-00 |
from US $9.76 |
||
