Air Inlet/throttle Linkage Diagram Mercury-Mercruiser E2.5
- Year
- 2.5
- Stroke (2-stroke or 4-stroke)
- 2 stroke
- Country
- USA
- Серийный номер
- 0G857000 THRU 0T999519
- Кол-в цилиндров
- 6
- Подача топлива
- EFI
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
993163 Gasket |
993163 |
US $35.10 |
||
|
2
|
2
816058T12 N.l.a. |
816058T12 |
US $1,649.90 |
||
| replacement | |||||
|
2
|
2
8M0084537 AIR INLET-ROS |
8M0084537 |
US $1,649.90 |
||
|
3
|
3
15133 Elbow |
15133 |
US $22.03 |
||
|
4
|
4
9871510 New Genuine Part |
9871510 |
US $129.70 |
||
|
5
|
5
848046A1 Shim Set |
848046A1 |
US $13.78 |
||
|
6
|
6
24836 Clip |
24836 |
US $3.71 |
||
|
7
|
7
69205 C washer |
69205 |
US $0.93 |
||
| replacement | |||||
|
7
|
7
8M0084613 C-Washer |
8M0084613 |
US $0.93 |
||
|
8
|
8
62568 Screw, , switch retainer to control panel |
62568 |
US $0.93 |
||
|
9
|
9
73013 Screw, 10-32 x 1.50, clamping plate |
73013 |
US $3.25 |
||
|
10
|
10
68219 Nut, stainless steel |
68219 |
US $3.40 |
||
|
11
|
11
48039 New Genuine Part |
48039 |
US $3.47 |
||
|
12
|
12
39349 Screw, stainless steel |
39349 |
US $1.62 |
||
|
13
|
13
814806 Washer, stainless steel |
814806 |
US $1.62 |
||
|
14
|
14
848023 Thrust Washer |
848023 |
US $8.98 |
||
|
15
|
15
90766
Screw (#10-32 X .500)
|
90766 |
— | ||
|
16
|
16
8154905 New Genuine Part |
8154905 |
US $634.35 |
||
|
17
|
17
821664
New Genuine Part
|
821664 |
— | ||
|
18
|
18
24800 Roll pin, control shaft |
24800 |
US $2.32 |
||
|
19
|
19
848024 Bushing (W/lip) |
848024 |
US $17.98 |
||
|
20
|
20
8480251 Bushing (W/o Lip) |
8480251 |
US $27.73 |
||
|
21
|
21
988941 Spring |
988941 |
US $29.55 |
||
|
22
|
22
137261 Lever-throttle |
137261 |
US $160.74 |
||
|
23
|
23
41355 Set screw |
41355 |
US $5.47 |
||
|
24
|
24
410891 Screw (#8-32 X 1.00) |
410891 |
US $5.22 |
||
|
25
|
25
26995 Lockwasher, starter solenoid terminal |
26995 |
US $0.93 |
||
|
26
|
26
809093
Bracket kit-tsp
|
809093 |
— | ||
|
27
|
27
53155 Screw (.250-20 X 2.50)(1/4-20 x 2-1/2 Inch) |
53155 |
US $1.50 |
||
|
27
|
27
63328 Screw, , cover to body(5/16-18 x 3 Inch) |
63328 |
US $5.57 |
||
|
28
|
28
35462 Washer, shift cable stud(1/4 Inch I.D.) |
35462 |
US $1.62 |
||
|
28
|
28
814806 Washer, stainless steel(5/16 Inch I.D.) |
814806 |
US $1.62 |
||
|
29
|
29
805979 Nut |
805979 |
US $1.75 |
||
| replacement | |||||
|
29
|
29
8M0214946 Nut |
8M0214946 |
US $1.75 |
||
|
30
|
30
89694 Key, coupling |
89694 |
US $7.65 |
||
|
31
|
31
8211532 New Genuine Part |
8211532 |
US $36.69 |
||
|
32
|
32
99365 Set screw |
99365 |
US $0.82 |
||
|
33
|
33
56762 New Genuine Part |
56762 |
US $0.35 |
||
|
33
|
33
816311T Tie Strap (8.00 Inches) |
816311T |
US $0.51 |
||
|
34
|
34
849620 Clip |
849620 |
US $9.31 |
||
|
35
|
35
89302 Washer |
89302 |
US $1.62 |
||
|
36
|
36
26996 Lockwasher, stainless steel, terminal block screws |
26996 |
US $1.04 |
||
|
37
|
37
69022 Screw |
69022 |
US $0.93 |
||
|
38
|
38
842050 Shim Throttle Shutter |
842050 |
US $7.65 |
||
|
NI
|
NI
849770A1 Gasket Set Engine |
849770A1 |
US $652.98 |
||
|
NI
|
NI
848040T40
Powerhead Assembly
|
848040T40 |
— | ||
| replacement | |||||
|
NI
|
NI
848040T48
POWERHEAD
|
848040T48 |
— | ||
