Upper casing Diagram Yamaha 25 ES/L
- Year
- 1986
- Model
- 25
- Year
- 1986
- Stroke (2-stroke or 4-stroke)
- 2 stroke
- Power
- 25
- Sales region
- U.S.A.
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
689-45111-01-EK
Casing, Upper
|
689-45111-01-EK |
— | ||
| replacement | |||||
|
1
|
1
689-45101-01-EK
Upper Case
|
689-45101-01-EK |
— | ||
|
1
|
1
689-45101-11-EK
Casing, Upper (689-45111-11-Ek)
689-45111-11-EK |
689-45101-11-EK |
— | ||
| replacement | |||||
|
1
|
1
689-45101-13-EK
CASING, UPPER
689-45111-11-EK |
689-45101-13-EK |
— | ||
|
2
|
2
689-41131-00-9M Exhaust Manifold 1 |
689-41131-00-9M |
US $208.62 |
||
| replacement | |||||
|
2
|
2
6A8-41131-10-5B Manifold, Ext. 1 |
6A8-41131-10-5B |
from US $93.35 |
||
|
3
|
3
689-45113-A1-00 Gasket, Upper Casing |
689-45113-A1-00 |
from US $16.37 |
||
| replacement | |||||
|
3
|
3
61T-45113-A0-00 Gasket, Upper Casing |
61T-45113-A0-00 |
from US $16.37 |
||
|
4
|
4
936-06120-19-00 Pin, Dowel |
936-06120-19-00 |
from US $2.86 |
||
|
5
|
5
97395-08030-00 Bolt |
97395-08030-00 |
US $2.69 |
||
| replacement | |||||
|
5
|
5
97080-08030-00 Bolt |
97080-08030-00 |
from US $2.91 |
||
|
6
|
6
92990-08600-00 Washer, Plate |
92990-08600-00 |
from US $1.66 |
||
|
7
|
7
689-41132-00-94
Manifold, Exhaust
|
689-41132-00-94 |
— | ||
|
7
|
7
689-41132-10-94
Manifold, Exhaust
|
689-41132-10-94 |
— | ||
| replacement | |||||
|
7
|
7
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
8
|
8
689-41137-00-94
Guide, Exhaust
|
689-41137-00-94 |
— | ||
|
9
|
9
97395-08020-00 Bolt, Hexagon |
97395-08020-00 |
from US $2.09 |
||
| replacement | |||||
|
9
|
9
97095-08020-00 Bolt |
97095-08020-00 |
from US $3.64 |
||
|
10
|
10
92990-08600-00 Washer, Plate |
92990-08600-00 |
from US $1.66 |
||
|
11
|
11
664-41134-00-00 Gasket, Exh.mani.2 |
664-41134-00-00 |
US $19.13 |
||
| replacement | |||||
|
11
|
11
664-41134-A0-00 Gasket, Exhaust Manifold |
664-41134-A0-00 |
from US $10.22 |
||
|
12
|
12
98580-06016-00 Screw Pan Head |
98580-06016-00 |
from US $2.70 |
||
|
13
|
13
689-41141-00-00 Seal 1 |
689-41141-00-00 |
from US $11.76 |
||
|
14
|
14
689-41142-00-00 Seal |
689-41142-00-00 |
from US $11.76 |
||
|
15
|
15
689-41135-00-00 Gasket, Exhaust Manifold |
689-41135-00-00 |
US $8.51 |
||
|
15
|
15
6A8-41135-00-00 Gasket, Exhaust Manifold |
6A8-41135-00-00 |
from US $4.95 |
||
|
16
|
16
914-90300-30-00 Pin. Cotter |
914-90300-30-00 |
from US $1.25 |
||
|
17
|
17
689-45127-00-00
Seal
|
689-45127-00-00 |
— | ||
