ｵﾙﾀﾈ-ﾄ 2 (25HEK/25HEMK ﾓﾃﾞﾙ) Diagram Yamaha 25 E(M)KS/L
- Year
- 1993
- Model
- 25H
- Model code
- 6J0
- Year
- 1993
- Stroke (2-stroke or 4-stroke)
- 2 stroke
- Power
- 25
- Sales region
- Japan (999)
- Colour
- Metallic Marine Silver (MMS; 00EK)
Difficulties in parts search?
Difficulties in parts search?
| Description | OEM Part # | Price | |||
|---|---|---|---|---|---|
|
1
|
1
689-81800-12-00 Starting Motor Assyスタ−テイングモ−タアセンブリ; |
689-81800-12-00 |
US $1,005.84 |
||
| replacement | |||||
|
1
|
1
689-81800-13-00 Starting Motor Assemblyスタ−テイングモ−タアセンブリ; |
689-81800-13-00 |
from US $601.33 |
||
|
2
|
2
689-81857-11-00 Retainer．リテ−ナ; |
689-81857-11-00 |
from US $13.82 |
||
|
3
|
3
689-81807-12-00 Gear Assy, Starting Motor．ギアアセンブリ，スタ−テイングモ−タ; |
689-81807-12-00 |
from US $139.25 |
||
|
4
|
4
689-81830-11-00 Front Bracket Assembly．フロントブラケツトアセンブリ; |
689-81830-11-00 |
from US $200.33 |
||
|
5
|
5
689-81844-11-00 Gasket．ガスケツト; |
689-81844-11-00 |
US $9.21 |
||
| replacement | |||||
|
5
|
5
689-81847-11-00 O-Ring．ガスケツト; |
689-81847-11-00 |
from US $9.21 |
||
|
6
|
6
689-81809-11-00 Washer Kit．ワツシヤキツト; |
689-81809-11-00 |
from US $12.89 |
||
|
7
|
7
689-81850-11-00 Armature Assy．ア−マチヤ−アセンブリ; |
689-81850-11-00 |
US $467.85 |
||
| replacement | |||||
|
7
|
7
689-81850-12-00 Armature Assy．ア−マチヤ−アセンブリ; |
689-81850-12-00 |
from US $362.77 |
||
|
8
|
8
689-81810-11-00 Stator Assy．ステ−タアセンブリ; |
689-81810-11-00 |
from US $187.90 |
||
|
9
|
9
689-81840-11-00 Brush Holder Assy．ブラシホルダアセンブリ; |
689-81840-11-00 |
from US $63.79 |
||
|
10
|
10
689-81812-11-00 Brush 2．．ブラシ ２; |
689-81812-11-00 |
from US $19.55 |
||
|
11
|
11
689-81811-11-00 Brush 1．ブラシ １; |
689-81811-11-00 |
from US $15.50 |
||
|
12
|
12
689-81813-10-00 Spring, Brush．スプリング，ブラシ; |
689-81813-10-00 |
from US $7.23 |
||
|
13
|
13
689-81820-11-00 Rear Bracket Assembly．リヤブラケツト アセンブリ; |
689-81820-11-00 |
from US $88.01 |
||
|
14
|
14
689-81826-10-00 Bolt．ボルト; |
689-81826-10-00 |
from US $9.35 |
||
|
15
|
15
97313-08012-00 Bolt (661) |
97313-08012-00 |
from US $3.12 |
||
| replacements | |||||
|
15
|
15
999-99999-99-00
Not Available
|
999-99999-99-00 |
— | ||
|
15
|
15
97013-08012-00 Bolt |
97013-08012-00 |
from US $3.12 |
||
|
16
|
16
92990-08600-00 Washer, Plateワツシヤ，プレ−ト; |
92990-08600-00 |
from US $1.66 |
||
|
17
|
17
689-15772-40-94
Stay 2
|
689-15772-40-94 |
— | ||
|
18
|
18
90109-06M24-00
Bolt
|
90109-06M24-00 |
— | ||
|
19
|
19
97313-06030-00 Bolt |
97313-06030-00 |
from US $2.83 |
||
| replacement | |||||
|
19
|
19
97080-06030-00 Bolt |
97080-06030-00 |
from US $2.83 |
||
|
20
|
20
929-90066-00-00 Washer, Plain (646)ワツシヤ，プレ−ト; |
929-90066-00-00 |
from US $1.39 |
||
|
21
|
21
973-13080-30-00
Bolt
|
973-13080-30-00 |
— | ||
| replacements | |||||
|
21
|
21
970-24080-30-00 Bolt |
970-24080-30-00 |
from US $1.55 |
||
|
21
|
21
970-17080-30-00 Bolt |
970-17080-30-00 |
from US $1.70 |
||
|
21
|
21
970-13080-30-00 Bolt |
970-13080-30-00 |
from US $3.47 |
||
|
22
|
22
92990-08600-00 Washer, Plateワツシヤ，プレ−ト; |
92990-08600-00 |
from US $1.66 |
||
